12
D10T Track-Type Tractor Specifications
Engine
Engine Model Cat ® C27 ACERT™
Gross Power
SAE J1995 482 kW 646 hp
ISO 14396 471 kW 632 hp
Net Power
SAE J1349/
ISO 9249
Min Fan 450 kW 603 hp
SAE J1349/
ISO 9249 433 kW 580 hp
80/1269/EEC 433 kW 580 hp
Bore 137.2 mm 5.4 in
Stroke 152.4 mm 6 in
Displacement 27 L 1,647.6 in 3
Engine ratings apply at 1,800 rpm. •
Net power advertised is the power available •
at the flywheel when the engine is equipped
with fan at max speed (unless otherwise
noted), air cleaner, muffler and alternator.
No derating required up to 4572 m (15,000 ft)
•
altitude.
Service Refill Capacities
Fuel Tank 1204 L 318 gal
Cooling System 151 L 39.9 gal
Engine Crankcase* 76 L 20.1 gal
Power Train 193 L 51 gal
Final Drives (each) 23 L 6.1 gal
Roller Frames (each) 64 L 16.9 gal
Pivot Shaft
Compartment 33 L 8.7 gal
*With oil filters.
Weights
Operating Weight 66 451 kg 146,499 lb
Shipping Weight 48 263 kg 106,402 lb
Operating Weight: Includes hydraulic •
controls, blade tilt cylinder, coolant,
lubricants, 100% fuel, ROPS, FOPS cab,
SU-Blade, Single-Shank Ripper, 610 mm
(24 in) ES shoes, and operator.
Shipping Weight: Includes coolant, lubricants,
•
20% fuel, ROPS, FOPS cab, and 610 mm
(24 in) ES shoes.
Undercarriage
Shoe Type Extreme Service
Width of Shoe 610 mm 24 in
Shoes/Side 44
Grouser Height 93 mm 3.7 in
Pitch 260 mm 10.2 in
Ground Clearance 615 mm 24.2 in
Track Gauge 2550 mm 100.4 in
Length of Track
on Ground 3885 mm 12 ft 9 in
Ground Contact
Area 4.7 m 2 7,326 in 2
Track Rollers/Side 8
Number of Carrier
Rollers 1 per side (optional)
Positive Pin Retention Track. •
Track Roller Frame
Oscillation 351 mm 13.8 in
Hydraulic Controls
Pump Type Gear
Lift Cylinder Flow 404 L/min 107 gal/min
Tilt Cylinder Flow
112 L/min 30 gal/min
Bulldozer Relief
Valve Setting 18 790 kPa 2,725 psi
Tilt Cylinder Relief
Valve Setting 20 340 kPa 2,950 psi
Ripper (Lift) Relief
Valve Setting 18 790 kPa 2,725 psi
Ripper (Pitch)
Relief Valve Setting 18 790 kPa 2,725 psi
Tank Capacity 144 L 38 gal
Pump output measured at 1,800 rpm •
and 6895 kPa (1,000 psi).
Electro-hydraulic pilot valve assists
•
operations of ripper and dozer controls.
Hydraulic system includes four valves
for use with blade and ripper.
Complete system consists of pump, tank
•
with filter, oil cooler, valves, lines, linkage
and control levers.
Steering and Brakes
Hydraulically
applied multiple-
disk clutches
diameter 392 mm 15.4 in
Transmission
1 Forward 4 km/h 2.5 mph
2 Forward 7.2 km/h 4.5 mph
3 Forward 12.7 km/h 7.9 mph
1 Reverse 5.2 km/h 3.2 mph
2 Reverse 9 km/h 5.6 mph
3 Reverse 15.8 km/h 9.8 mph
1 Forward – Max
Drawbar Pull (1000) 1000.9 N 225 lbf
2 Forward – Max
Drawbar Pull (1000) 556 N 125 lbf
3 Forward – Max
Drawbar Pull (1000) 306.9 N 69 lbf
