Pistol Assembly
www.sphinxarms.com 19
3
2
1
Align
Barrel locking lug
4
1. Insert the barrel into the slide.
2. Push the recoil spring guide into place and ensure that the recoil spring guide is
properly centered against the barrel locking lug.
3. Place the slide onto the frame and glide it all the way back into position.
4. Realign the disassembly lines on the slide and frame, and insert the Slidestop lever
from the left side of the frame until secured.
HANDLING AND OPERATION
