Document Number: 93160 For technical questions, contact: [email protected] www.vishay.com
Revision: 14-Dec-09 5
VSKS500-08PbF
MAP Block Power Module
Single Thyristor, 500 A
Vishay High Power Products
Fig. 7 - On-State Voltage Drop Characteristics
Fig. 8 - Thermal Impedance Z
thJC
Characteristics
ORDERING INFORMATION TABLE
Instantaneous On-
S
tate Current (A)
Instantaneous On-State Voltage (V)
0 0.5 1.0 1.5 2.0 2.5 3.0
1
100
10
10 000
1000
93160_07
T
J
= 130 °C
0.001
0.01
0.1
0.001
93160_08
0.01 0.1 1 10
Square Wave Pulse Duration (s)
Z
thJC
- Transient Thermal
Impe
d
ance (K/W)
100
1 - Module type
2 - Circuit configuration (S = Single SCR)
3 - Current rating (500 = 500 A)
4 - Voltage rating (08 = 800 V)
5 - PbF = Lead (Pb)-free
Device code
4 1 3 2 5
VSK S 500 - 08 PbF
