MAP Block Power Module Single Thyristor, 500 A
VSKS500-08PbF
Vishay High Power Products
FEATURES
• Electrically isolated base plate
• 3000 V
RMS
isolating voltage
• Industrial standard package
• Simplified mechanical designs, rapid assembly
• High surge capability
• Large creepage distances
• Compliant to RoHS directive 2002/95/EC
APPLICATIONS
• Battery chargers
• Welders
• Power converters
• Alternators
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
T(AV)
500 A
MAP Block Power
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL CHARACTERISTICS VALUES UNITS
V
DRM
/V
RRM
800 V
I
T(AV)
500 A
T
C
76 °C
I
TSM
50 Hz 14 000
A
60 Hz 14 658
I 2 t
50 Hz 980
kA 2 s
60 Hz 894
I 2 √t 9800 kA 2 √s
T
J
Range - 40 to 130 °C
VOLTAGE RATINGS
TYPE NUMBER
V
RRM
/V
DRM
, MAXIMUM
REPETITIVE PEAK
REVERSE VOLTAGE
V
V
RSM
/V
DSM
, MAXIMUM
NON-REPETITIVE PEAK
REVERSE VOLTAGE
V
I
RRM
/I
DRM
AT 130 °C
mA
VSKS500-08PbF 800 900 80
