VS-GT50TP120N

www.vishay.com

Vishay Semiconductors

Revision: 17-May-13

2

Document Number: 94824

For technical questions within your region:

[email protected]

,

[email protected]

,

[email protected]

THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT

ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT

www.vishay.com/doc?91000

IGBT ELECTRICAL SPECIFICATIONS (T

C

= 25 °C unless otherwise noted)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN.

TYP.

MAX. UNITS

Collector to emitter breakdown voltage

V

(BR)CES

T

J

= 25 °C

1200

-

-

V

Collector to emitter voltage

V

CE(on)

V

GE

= 15 V, I

C

= 50 A, T

J

= 25 °C

-

1.90

2.35

V

GE

= 15 V, I

C

= 50 A, T

J

= 175 °C

-

2.50

-

Gate to emitter threshold voltage

V

GE(th)

V

CE

= V

GE

, I

C

= 1.4 mA, T

J

= 25 °C

5.0

5.5

7.5

Collector cut-off current

I

CES

V

CE

= V

CES

, V

GE

= 0 V, T

J

= 25 °C

-

-

5.0

mA

Gate to emitter leakage current

I

GES

V

GE

= V

GES

, V

CE

= 0 V, T

J

= 25 °C

-

-

400

nA

SWITCHING CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN.

TYP.

MAX. UNITS

Turn-on delay time

t

d(on)

V

CC

= 600 V, I

C

= 50 A, R

g

= 15

,

V

GE

= ± 15 V, T

J

= 25 °C

-

148

-

ns

Rise time

t

r

-

84

-

Turn-off delay time

t

d(off)

-

245

-

Fall time

t

f

-

251

-

Turn-on switching loss

E

on

-

5.51

-

mJ

Turn-off switching loss

E

off

-

2.70

-

Turn-on delay time

t

d(on)

V

CC

= 600 V, I

C

= 50 A, R

g

= 15

,

V

GE

= ± 15 V, T

J

= 125 °C

-

263

-

ns

Rise time

t

r

-

81

-

Turn-off delay time

t

d(off)

-

256

-

Fall time

t

f

-

292

-

Turn-on switching loss

E

on

-

6.63

-

mJ

Turn-off switching loss

E

off

-

3.25

-

Input capacitance

C

ies

V

GE

= 0 V, V

CE

= 30 V, f = 1.0 MHz

-

6.24

-

nF

Output capacitance

C

oes

-

0.23

-

Reverse transfer capacitance

C

res

-

0.15

-

SC data

I

SC

t

p

 10 μs, V

GE

= 15 V, T

J

= 125 °C,

V

CC

= 600 V, V

CEM

 1200 V

-

450

-

A

Stray inductance

L

CE

-

-

30

nH

Module lead resistance, terminal to chip

R

CC’+EE’

-

0.75

-

m

DIODE ELECTRICAL SPECIFICATIONS (T

C

= 25 °C unless otherwise noted)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN.

TYP.

MAX.

UNITS

Forward voltage

V

F

I

F

= 50 A

T

J

= 25 °C

-

1.85

2.25

V

T

J

= 125 °C

-

1.95

-

Reverse recovery charge

Q

rr

I

F

= 50 A, V

R

= 600 V,

dI

F

/dt = - 654 A/μs

V

GE

= - 15 V

T

J

= 25 °C

-

3.1

-

μC

T

J

= 125 °C

-

6.1

-

Peak reverse recovery current

I

rr

T

J

= 25 °C

-

24

-

A

T

J

= 125 °C

-

31

-

Reverse recovery energy

E

rec

T

J

= 25 °C

-

0.98

-

mJ

T

J

= 125 °C

-

2.06

-
