UFL200FA60P
Vishay Semiconductor Italy
www.vishay.com
2
Document Number: I27322
Revision 30-Oct-07
R
thJC
Junction to Case, Single Leg Conducting 0.5 °C/W
Both Leg Conducting 0.25 K/W
R
thCS
Case to Heat Sink, Flat, Greased Surface 0.05
Wt Weight 30 g
T Mounting Torque 1.3 (N•m)
PARAMETERS MIN TYP MAX Units
t
rr
Reverse Recovery Time 102 141 ns T
J
= 25°C
- 210 293 T
J
= 125°C
I
RRM
Peak Recovery Current - 9 12 A T
J
= 25°C
- 21 25 T
J
= 125°C
Q
rr
Reverse Recovery Charge - 443 744 nC T
J
= 25°C
- 2086 3355 T
J
= 125°C
I
F
= 50A
V
R
= 200V
di
F
/dt = 200A/μs
DYNAMIC RECOVERY CHARACTERISTICS @ T
J
= 25°C (UNLESS OTHERWISE SPECIFIED)
THERMAL-MECHANICAL SPECIFICATIONS
V
BR
Cathode Anode 600 - - V I
R
= 100μA
Breakdown Voltage
V
FM
Forward Voltage - 1.28 1.44 V I
F
= 100A
- 1.48 1.66 V I
F
= 200A
- 1.13 1.24 V I
F
= 100A, T
J
= 125°C
- 1.37 1.55 V I
F
= 200A
I
RM
Reverse Leakage Current - 5 100 μA V
R
= V
R
Rated
- 0.2 1 mA T
J
= 175°C, V
R
= V
R
Rated
C
T
Junction Capacitance - 80 - pF V
R
= 600V
PARAMETERS MIN TYP MAX UNITS TETS CONDITIONS
ELECTRICAL CHARACTERISTICS @ T
J
= 25°C (UNLESS OTHERWISE SPECIFIED)
PARAMETERS MIN TYP MAX UNITS TETS CONDITIONS
