Document Number: 93281
For technical questions, contact:
www.vishay.com
Revision: 05-May-11
1
This document is subject to change without notice.
THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Thyristor/Thyristor
(SUPER MAGN-A-PAK Power Modules), 570 A
VSKT570-18PbF
Vishay Semiconductors
FEATURES
• High current capability
• High surge capability
• Industrial standard package
• 3000 V
RMS
isolating voltage with non-toxic substrate
• Compliant to RoHS Directive 2002/95/EC
• Designed and qualified for industrial level
TYPICAL APPLICATIONS
• Motor starters
• DC motor controls - AC motor controls
• Uninterruptable power supplies
ELECTRICAL SPECIFICATIONS
PRODUCT SUMMARY
I
T(AV)
570 A
SUPER MAGN-A-PAK
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL
CHARACTERISTICS
VALUES
UNITS
I
T(AV)
T
C
= 74 °C
570
A
I
T(RMS)
T
C
= 74 °C
895
I
TSM
50 Hz
17 800
60 Hz
18 700
I
2
t
50 Hz
1591
kA
2
s
60 Hz
1452
I
2
t
15 910
kA
2
s
V
RRM
1800
V
T
Stg
Range
- 40 to 135
°C
T
J
Range
- 40 to 135
VOLTAGE RATINGS
TYPE NUMBER
VOLTAGE
CODE
V
RRM
/V
DRM
, MAXIMUM REPETITIVE
PEAK REVERSE VOLTAGE
V
V
RSM
, MAXIMUM NON-REPETITIVE
PEAK REVERSE VOLTAGE
V
I
RRM
/I
DRM
MAXIMUM
AT T
J
= T
J
MAXIMUM
mA
VSKT570-18PbF
18
1800
1900
120
