4
PM1200HCE330-1
High Voltage Intelligent Power Module
1200 Amperes/3300 Volts
Powerex, Inc., 200 E. Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Thermal Characteristics
Characteristics Symbol Test Conditions Min. Typ. Max. Units
Thermal Resistance, Junction to Case R
th(j-c)
Q Per IGBT — 0.0083 0.0100 ° C/W
Thermal Resistance, Junction to Case R
th(j-c)
D Per FWDi — 0.0167 0.0200 ° C/W
Contact Thermal Resistance R
th(c-f)
Per Module, Thermal Grease Applied — 0.0075 — ° C/W
Recommended Conditions for Use
Characteristics Symbol Test Conditions Min. Typ. Max. Units
Inverter Supply Voltage V CC Applied between C-E 0 1500 2200 Volts
Control Supply Voltage V
D
Applied between V
1
-V
C
21.6 24.0 26.4 Volts
Input ON Voltage V
CIN(on)
Applied between C
1
-V
C
0 — 4.0 Volts
Input OFF Voltage V
CIN(off)
— 16.0 — V
D
Volts
PWM Input Frequency f
PWM
3 Phase Sinsusoidal PWM Control — 0.5 2.0 kHz
Arm Shoot-though Blocking Time t DEAD Reference at IPM's Input Terminals 8.0 — — µ s
EMITTER CURRENT, I
E
, (AMPERES)
FREE-WHEEL DIODE
FORWARD CHARACTERISTICS
(TYPICAL)
EMITTER COLLECTOR VOLTAGE, V
EC
, (VOLTS)
COLLECTOR CURRENT, I
C
, (AMPERES)
COLLECTOR-EMITTER
SATURATION VOLTAGE, V
CE(sat)
, (VOLTS
)
COLLECTOR-EMITTER
SATURATION VOLTAGE CHARACTERISTICS
(TYPICAL)
5
3
4
0 500 1500
2
1
0
2000
V GE = 15V
T
j
= 25 ° C
T
j
= 125 ° C
V CC = 1500V
I
C
/-I
C
= 1200A
T j = 125 ° C
T
j
= 25 ° C
T
j
= 125 ° C
1000
4
3
0 500 1500
2
1
0
2000 1000
E ON /E OFF COLLECTOR CURRENT, I
C
, (AMPERES)
E REC
EMITTER CURRENT, I
E
, (AMPERES)
SWITCHING ENERGY CHARACTERISTICS
(TYPICAL)
SWITCHING ENERGY, E
ON
/E
OFF
/E
REC
, (J/PULSE)
3
0 500 1500
2
1
0
2000 1000
E
ON
E
OFF
E
REC
