2
PM1200HCE330-1
High Voltage Intelligent Power Module
1200 Amperes/3300 Volts
Powerex, Inc., 200 E. Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Absolute Maximum Ratings, T
j
= 25 °C unless otherwise specified
Ratings Symbol PM1200HCE330-1 Units
Junction Temperature T
j
-40 to 150 ° C
Storage Temperature T
stg
-40 to 115 ° C
Mounting Torque, M6 Mounting Screws – 30 in-lb
Mounting Torque, M8 Main Terminal Screw – 95 in-lb
Mounting Torque, M3 Auxiliary Terminal Screw – 5 in-lb
Weight (Typical) – 1.5 kg
Isolation Voltage (Main Terminal to Baseplate, AC 1 min.) V
iso
6000 Volts
Control Part
Supply Voltage Applied between V 1 ~ V C V D 26.4 Volts
Input Voltage Applied between C
1
~ V
C
V
CIN
26.4 Volts
Fault Output Supply Voltage Applied between F
O
-V
C
V
FO
26.4 Volts
Fault Output Current (Sink Current at F
O
Terminals) I
FO
20 mA
Inverter Part
Collector-Emitter Voltage V
CES
3300 Volts
Collector Current I C 1200 Amperes
Peak Collector Current I
CP
2400 Amperes
2
