Bulletin I27201 rev. A 01/06
GA100TS60SF
Fig. 1 - Typical Output Characteristics
I C
, Collector-to-Emitter Current (A)
V
CE
, Collector-to-Emitter Voltage (V)
Fig. 2 - Typical Transfer Characteristics
I C
, Collector-to-Emitter Current (A)
V
GE
, Gate-to-Emitter Voltage (V)
Fig. 4 - Typical Collector-to-Emitter Voltage
vs. Junction Temperature
V
CE
, Collector-to-Emitter Voltage (V)
T
J
, Junction Temperature (°C)
Fig. 3 - Maximum Collector Current
vs. Case Temperature
Maximum DC Collector Current (A)
T
C
, Case Temperature (°C)
1
10
100
1000
5.5 6.5 7.5 8.5
Vce = 10V
380µs PULSE WIDTH
T = 25˚C
T = 125˚C
J
J
0.7
0.9
1.1
1.3
1.5
25 50 75 100 125 150
I = 50A
I = 100A
I = 200A
C
C
10
100
1000
0.6 0.8 1 1.2 1.4 1.6 1.8
Tj = 25˚C
Vge = 15V
Tj = 125˚C
0
40
80
120
160
200
240
25 50 75 100 125 150
