VSKD91.., VSKC91.., VSKJ91.., VSKE91.. Series
ADD-A-PAK Generation VII
Power Modules Standard Diodes, 100 A
Vishay Semiconductors
CIRCUIT CONFIGURATION
CIRCUIT DESCRIPTION
CIRCUIT
CONFIGURATION CODE
CIRCUIT DRAWING
Two diodes doubler circuit D
Two diodes common cathodes C
Two diodes common anodes J
Single diode E
LINKS TO RELATED DOCUMENTS
Dimensions www.vishay.com/doc?95369
VSKD...
~
(1) (3) (2)
- +
1
2 3
+ - -
VSKC...
(1) (3) (2)
1
2 3
- + +
VSKJ...
(1) (3) (2)
1
2 3
- +
VSKE...
1
2 3
(3) (2)
