VSKD91.., VSKC91.., VSKJ91.., VSKE91.. Series
Vishay Semiconductors
ADD-A-PAK Generation VII
Power Modules Standard Diodes, 100 A
Fig. 10 - Forward Voltage Characteristics
Fig. 11 - Thermal Impedance Z
thJC
Characteristics
ORDERING INFORMATION TABLE
Note
• To order the optional hardware go to
www.vishay.com/doc?95172
Instantaneous forward voltage (V)
Instantaneous forward current (A)
0
0.5
1.0
1.5
2.0
2.5
3.0
1
10
100
1000
Tj = 25°C
Tj = 150°C
Per leg
Square wave pulse duration (s)
Transient thermal impedance Z
thJC
(°C/W)
0.001
0.01
0.1
1
10
0.01
0.1
1
Steady state value
RthJC = 0.22 °C/W
(DC operation)
Per leg
1
-
Module type
2
-
Circuit configuration (see Circuit Configuration table)
3
-
Current code (100 A)
4
-
Voltage code (see Voltage Ratings table)
Device code
4
1
3
2
VSK
D
91
/
16
