PS21997-4, PS21997-4A
Intellimod™ Module
Dual In-line Intelligent Power Module
30 Amperes/600 Volts
Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
4
10/09
Thermal Characteristics
Characteristic
Symbol
Condition
Min.
Typ.
Max.
Units
Junction to Case
R
th(j-c)
Q
Inverter IGBT (Per 1/6 Module)
—
—
2.1
°C/Watt
Junction to Case
R
th(j-c)
D
Inverter FWDi (Per 1/6 Module)
—
—
3.0
°C/Watt
Recommended Conditions for Use
Characteristic
Symbol
Condition
Min.
Typ. Value Units
Supply Voltage
V
CC
Applied between P-N Terminals
0
300
400
Volts
Control Supply Voltage
V
D
Applied between V
P1
-V
NC
, V
N1
-V
NC
13.5
15.0
16.5 Volts
V
DB
Applied between V
UFB
-U,
13.0
15.0
18.5 Volts
V
VFB
-V, V
WFB
-W
Control Supply Variation
dV
D
, dV
DB
-1
—
1
V/µs
Arm Shoot-through Blocking Time
t
DEAD
For Each Input Signal, T
C
≤ 100°C
2.0
—
—
µs
PWM Input Frequency
f
PWM
T
C
≤ 100°C, T
j
≤ 125°C
—
—
20
kHz
Allowable Minimum Input
P
WIN(on)
**
200V ≤ V
CC
≤ 350V,
0.5
—
—
µs
Pulse Width
P
WIN(off)
***
13.5V ≤ V
D
≤ 16.5V,
Below Rated Current
1.5
—
—
µs
13.0V ≤ V
DB
≤ 18.5V
Between Rated Current 3.0
—
—
µs
-20°C ≤ T
C
≤ 100°C,
and 1.7 Times
N-line Wiring Inductance
Rated Current
Less than 10nH
V
NC
Voltage Variation
V
NC
Between V
NC
-N (Including Surge)
-5.0
—
5.0
Volts
*The allowable rms current value depends on the actual application conditions.
**Input signal with ON pulse width less than P
WIN(on)
may not respond.
***Input signal with OFF pulse width less than PWIN(off) may make no resonse or may have a delayed response to P-side input only. The delay is less than 4µs.
