PS21997-4, PS21997-4A
Intellimod™ Module
Dual In-line Intelligent Power Module
30 Amperes/600 Volts
Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
3
10/09
Electrical and Mechanical Characteristics,
T
j
= 25°C unless otherwise specified
Characteristics
Symbol
Test Conditions
Min.
Typ.
Max.
Units
IGBT Inverter Sector
Collector-Emitter Saturation Voltage
V
CE(sat)
V
D
= V
DB
= 15V, I
C
= 30A, V
IN
= 5V, T
j
= 25°C
—
1.90
2.50
Volts
V
D
= V
DB
= 15V, I
C
= 30A, V
IN
= 5V, T
j
= 125°C
—
2.00
2.60
Volts
Diode Forward Voltage
V
EC
T
j
= 25°C, -I
C
= 30A, V
IN
= 0V
—
1.70
2.20
Volts
Switching Times
t
on
V
CC
= 300V,
0.70
1.30
1.90
µs
t
rr
V
D
= V
DB
= 15V,
—
0.30
—
µs
t
C(on)
I
C
= 30A, T
j
= 125°C,
—
0.40
0.60
µs
t
off
V
IN
= 0 ⇔ 5V,
—
1.70
2.65
µs
t
C(off)
Inductive Load (Upper and Lower Arm)
—
0.40
1.00
µs
Collector-Emitter Cutoff Current
I
CES
V
CE
= V
CES
, T
j
= 25°C
—
—
1.0
mA
V
CE
= V
CES
, T
j
= 125°C
—
—
10
mA
Control Sector
Circuit Current I
D
V
IN
= 5V
Total of V
P1
-V
NC
, V
N1
-V
NC
—
—
2.80
mA
V
D
= V
DB
= 15V
V
UFB
-U, V
VFB
-V, V
WFB
-W
—
—
0.55
mA
V
IN
= 0V
Total of V
P1
-V
NC
, V
N1
-V
NC
—
—
2.80
mA
V
UFB
-U, V
VFB
-V, V
WFB
-W
—
—
0.55
mA
Fault Output Voltage
V
FOH
V
SC
= 0V, F
O
Terminal Pull-up to 5V by 10kΩ
4.9
—
—
Volts
V
FOL
V
SC
= 1V, I
FO
= 1mA
—
—
0.95
Volts
Short Circuit Trip Level*
V
SC(ref)
V
D
= 15V
0.43
0.48
0.53
Volts
Input Current
I
IN
V
IN
= 5V
0.70
1.00
1.50
mA
Supply Circuit Under-voltage
UV
DBt
Trip Level, T
j
≤ 125°C
10.0
—
12.0
Volts
Protection
UV
DBr
Reset Level, T
j
≤ 125°C
10.5
—
12.5
Volts
UV
Dt
Trip Level, T
j
≤ 125°C
10.3
—
12.5
Volts
UV
Dr
Reset Level, T
j
≤ 125°C
10.8
—
13.0
Volts
Fault Output Pulse Width**
t
FO
40
—
—
µs
ON Threshold Voltage
V
th(on)
Applied between
—
2.1
2.6
Volts
OFF Threshold Voltage
V
th(off)
U
P
, V
P
, W
P,
0.8
1.3
—
Volts
ON/OFF Threshold Hysteresis Voltage
V
th(hys)
U
N
, V
N
, W
N
-V
NC
0.35
0.65
—
Volts
* Short Circuit protection is functioning only for the low-arms. Please select the value of the external shunt resistor such that the SC trip level is less than 1.7 times the current rating.
**Fault signal is asserted only for a UV or SC condition on the low side. On a SC fault the FO duration will be 40µsec. On a UV condition the fault signal will be asserted as long as the
UV condition exists or for 40µsec, whichever is longer.
