PM15CZF120
Intellimod™ Modules
Three Phase Converter IGBT Inverter Output
15 Amperes/1200 Volts
510
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
TIME, (s)
TRANSIENT THERMAL
IMPEDANCE CHARACTERISTICS
(FWDi)
10 1
10 -1 10 0 10 1
10 0
10 -1
10 -2
10 -3
SINGLE PULSE
STANDARD VALUE = R
th(j-c)D = 4.5 o C/W
10 -2 10 -3 TRANSIENT IMPEDANCE, Z
th
(j-c)
, (NORMALIZED VALUE)
TIME, (s)
TRANSIENT IMPEDANCE, Z
th
(j-c)
, (NORMALIZED VALUE)
TRANSIENT THERMAL
IMPEDANCE CHARACTERISTICS
(IGBT)
10 1
10 -1 10 0 10 1
10 0
10 -1
10 -2
10 -3
SINGLE PULSE
STANDARD VALUE = R
th(j-c)Q = 1.5 o C/W
10 -2 10 -3
