PM15CZF120
Intellimod™ Modules
Three Phase Converter IGBT Inverter Output
15 Amperes/1200 Volts
506
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Absolute Maximum Ratings, T
j
= 25
°
C unless otherwise specified
Characteristics Symbol PM15CZF120 Units
Junction Temperature T
j
–20 to 150
°
C
Storage Temperature T
stg
–40 to 125
°
C
Case Operating Temperature T C -20 to 100
°
C
Mounting Torque M5 Mounting Screws – 17 in-lb
Module Weight (Typical) – 80 Grams
Supply Voltage Protected by OC and SC (V
D
= 13.5 ~ 16.5V, Inverter Part) V
CC(prot)
800 Volts
Isolation Voltage, AC 1 minute, 60Hz Sinusoidal V
RMS
2500 Volts
Control Sector
Supply Voltage Applied between (V
UP1
-V
UPC
, V
VP1
-V
VPC
, V
WP1
-V
WPC
, V
N1
-V
NC
) V
D
20 Volts
Input Voltage Applied between (U
P
, V
P
, W
P
, U
N
, V
N
, W
N
) V
CIN
20 Volts
Fault Output Supply Voltage (Applied between F O and V NC ) V FO 20 Volts
Fault Output Current I
FO
20 mA
IGBT Inverter Sector
Collector-Emitter Voltage (V D = 15V, V CIN = 15V) V CES 1200 Volts
Collector Current,
±
I C 15 Amperes
Peak Collecotr Current, ± I
CP
30 Amperes
Supply Voltage (Applied between P-N) V
CC
900 Volts
Supply Voltage, Surge (Applied between P-N, Surge Value) V
CC (surge)
1000 Volts
Collector Dissipation P
C
83 Watts
