GB100TS60NPbF
Vishay High Power Products
INT-A-PAK "Half-Bridge"
(Ultrafast Speed IGBT),
108 A
ELECTRICAL CHARACTERISTICS (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL
TEST
CONDITIONS
MIN.
TYP.
MAX.
UNITS
Collector to emitter breakdown voltage
V
BR(CES)
V
GE
= 0 V, I
C
= 500 µA
600
-
-
V
Collector to emitter voltage
V
CE(on)
V
GE
= 15 V, I
C
= 50 A
-
1.95
2.1
V
GE
= 15 V, I
C
= 100 A
-
2.6
2.85
V
GE
= 15 V, I
C
= 50 A, T
J
= 125 °C
-
2.21
2.44
V
GE
= 15 V, I
C
= 100 A, T
J
= 125 °C
-
3.05
3.38
Gate threshold voltage
V
GE(th)
V
CE
= V
GE
, I
C
= 500 µA
3
4.6
6
Collector to emitter leakage current
I
CES
V
GE
= 0 V, V
CE
= 600 V
-
0.01
0.1
mA
V
GE
= 0 V, V
CE
= 600 V, T
J
= 150 °C
-
3.7
10
Diode forward voltage drop
V
FM
I
C
= 50 A
-
1.35
1.66
V
I
C
= 100 A
-
1.57
1.96
I
C
= 50 A, T
J
= 125 °C
-
1.27
1.50
I
C
= 100 A, T
J
= 125 °C
-
1.57
1.89
Gate to emitter leakage current
I
GES
V
GE
= ± 20 V
-
-
± 200
nA
SWITCHING CHARACTERISTICS (T
J
= 25 °C unless otherwise specified)
PARAMETER SYMBOL
TEST
CONDITIONS
MIN.
TYP.
MAX.
UNITS
Turn-on switching loss
E
on
I
C
= 100 A, V
CC
= 360 V, V
GE
= 15 V,
R
G
= 4.7
Ω, L = 200 µH
-
0.6
-
mJ
Turn-off switching loss
E
off
-
1.1
-
Total switching loss
E
tot
-
1.7
-
Turn-on switching loss
E
on
I
C
= 100 A, V
CC
= 360 V, V
GE
= 15 V,
R
G
= 4.7
Ω, L = 200 µH, T
J
= 125 °C
-
0.8
-
Turn-off switching loss
E
off
-
1.3
-
Total switching loss
E
tot
-
2.1
-
Turn-on delay time
t
d(on)
-
197
-
ns
Rise time
t
r
-
50
-
Turn-off delay time
t
d(off)
-
225
-
Fall time
t
f
-
72
-
Reverse bias safe operating area
RBSOA
T
J
= 150 °C, I
C
= 200 A,
R
G
= 27
Ω, V
GE
= 15 V to 0
Fullsquare
Short circuit safe operating area
SCSOA
T
J
= 150 °C, V
CC
= 400 V, V
P
= 600 V,
R
G
= 27
Ω, V
GE
= 15 V to 0
10
-
-
Diode reverse recovery time
t
rr
I
F
= 50 A, dI
F
/dt = 200 A/µs,
V
CC
= 400 V, T
J
= 25 °C
-
116
140
ns
Diode peak reverse current
I
rr
-
11
15
A
Diode recovery charge
Q
rr
-
600
1050
nC
Diode reverse recovery time
t
rr
I
F
= 50 A, dI
F
/dt = 200 A/µs,
V
CC
= 400 V, T
J
= 125 °C
-
152
190
ns
Diode peak reverse current
I
rr
-
16
20
A
Diode recovery charge
Q
rr
-
1215
1900
nC
