CM75MX-12A
NX-Series CIB Module
(3Ø Converter + 3Ø Inverter + Brake)
75 Amperes/600 Volts
Powerex, Inc., 173 Pavilion Lane, Youngwood, Pennsylvania 15697 (724) 925-7272 www.pwrx.com
5
Rev. 11/11
– :
CONC
A
VE
+ :
CONVEX
– : CONCAVE
X
Y
+ : CONVEX
MOUNTING
SIDE
MOUNTING SIDE
MOUNTING SIDE
Thermal Resistance Characteristics,
T
j
= 25°C unless otherwise specified
Characteristics
Symbol
Test Conditions
Min.
Typ.
Max.
Units
Thermal Resistance, Junction to Case
R
th(j-c)
Q
Per Inverter IGBT
*4
— — 0.44 °C/W
Thermal Resistance, Junction to Case
R
th(j-c)
D
Per Inverter FWDi
*4
— — 0.85 °C/W
Thermal Resistance, Junction to Case
R
th(j-c)
Q
Brake IGBT
*4
— — 0.44 °C/W
Thermal Resistance, Junction to Case
R
th(j-c)
D
Brake ClampDi
*4
— — 0.85 °C/W
Thermal Resistance, Junction to Case
R
th(j-c)
D
Per ConvDi
*4
— — 0.24 °C/W
Contact Thermal Resistance
R
th(c-s)
Case to Heatsink, Per 1 Module
—
0.015
—
°C/W
Thermal Grease Applied
*4,*7
Mechanical Characteristics
Characteristics
Symbol
Test Conditions
Min.
Typ.
Max.
Units
Mounting Torque, M5 Mounting Screws
—
31
in-lb
Module Weight (Typical)
—
270
Grams
Isolation Voltage, (Charged Part to Baseplate, RMS, f = 60Hz, AC 1 min.)
V
ISO
2500 Volts
Flatness of Baseplate
*8
e
c
±0 to +100
µm
*4 Case temperature (T
C
) and heatsink temperature (T
s
) is measured on the surface
(mounting side) of the baseplate and the heatsink side just under the chips.
Refer to the figure to the right for chip location.
The heatsink thermal resistance should be measured just under the chips.
*7 Typical value is measured by using thermally conductive grease of λ = 0.9 [W/(m • K)].
*8 Baseplate (mounting side) flatness measurement points (X, Y) are shown in the figure below.
0
0
0
0
1
2
3 4 5
6
7 8
9 10 11 12 13 14 15 16 17 18 19 20 21 22
53
54
55
56
57
58
59
60
61
30
29
28
27
26
25
24
23
52 51 50 49 48 47 46 45 44 43 42 41 40 39 38 37 36 35 34 33 32 31
V
P
W
P
W
N
Br
V
N
U
N
U
P
TN
SN
RN
RP SP TP
64.2
73.0
77
.8
81
.4
86.1 91
.4
97
.9
27.6
34.7
41.2
42.0
25.5
42.9
26.5
29.5
26.6
37
.0
47
.4
29.5
39.9
50.3
65.5
Th
95.5
10
1.
2
89.6
98.2
74.6
71
.0
17.8
27.1
33.6 35.2
Dimensions in mm (Tolerance: ±1mm)
IGBT FWDi Converter Diode NTC Thermistor
Chip Location (Top View)
84.6
U
P
V
P
W
P
W
N
V
N
U
N
Br
