PROFIBUS PA
Field-bus components for industrial applications with tension clamp connection
PROFIBUS PA
53
The measuring instruments are connected directly in the distributor via the EMC cable gland.
The screen is connected to the housing via the EMC cable gland.
A A A B B B S S S
off on
C1 R1
19
58
64
off on
Bus terminator:
Circuit diagram
Circuit diagram
A PA- (3)
S Shielding (4)
B PA+ (1)
n.c. (2)
Bus Terminator
A
A
A
S
S
S
B
B
B
1uF 50Vdc
C1
R1
100R
off on
Wire bridge
Enclosure
PROFIBUS-PA T-Connector EMC version 1-way
Type FBCon PA CG 1way
R1
A B S A B S A B S A B S
on
off C1
98
19
64
off on
Bus terminator:
A PA- (3)
S Shielding (4)
B PA+ (1)
n.c. (2)
A
A A
A
S
S S
S
B
B B
B
1uF 50Vdc
C1
100R
R1 off on
Bus Terminator
Wire bridge
Enclosure
PROFIBUS-PA T-Connector EMC version 2-way
Type FBCon PA CG 2way
Ordering data
Type Cat. No.
Profibus PA T distributor type FBCon PA CG 2way 8564100000
Ordering data
Type Cat. No.
Profibus PA T distributor type FBCon PA CG 1way 8564090000
