KT-MB-GTB-2PS
Technical data
R
e
le
ase
da
te
20
09
-0
4-
24
14
:53
D
ate
of
i
ssue
20
09
-0
4-
24
19
94
93-
0
007
_E
N
G.xm
l
3
Description:
1
PROFIBUS DP/PA Gateway HD2-GTB-2PA
2
Motherboard MBCB-FB-GT
3
Power supply connection
4
Power supply module HD2-FBPS-1.25.360
5
Ground connection clamp
6
PA-Trunk connection
7
PROFIBUS DP connection
8
Quick-Lok bar
Scope of delivery:
1 x HD2-GTB-2PA
1 x MBCB-FB-GT
2 x HD2-FBPS-1.25.360
Dimensions
DP/P
HD2-
GTR-
4P A
Seg2
Seg1
PWR
DP/
ERR
1
2
3
4
5
6
7
8
108 (4.2)
200 (7.8)
162 (6.3)
All dimensions in millimeters and inches (values in brackets) and without tolerance indication.
