Technical Data
KLD2-PL-Ex1.PA
096
79
0_
EN
G.xm
l
2
003
-02-
2
7
Supply
Connection
Power Rail or terminals 59+, 60-, 58 FE
Rated voltage
20 ... 35 V DC
Ripple
≤ 10 %
Rated current
430 mA ... 190 mA
Fieldbus connection
Profibus PA
Connection
terminals 3, 18+; 2, 17-; 1, 16 screen
Rated voltage
12,8 ... 13,4 V
Rated current
≤ 100 mA
Protocol
PROFIBUS DP V1
Terminating impedance
100
Ω , integrated
Connection to gateway
Connection
Power Rail or terminals 40+, 41-, 42S to CH1 ... CH4 of the KLD2-GT-DP(R)-xPA
Baudrate
31,25 kBit/s
Electrical isolation
Connection to gateway/PROFIBUS PA
safe electrical isolation acc. to EN 50020, voltage peak value 375 V
Connection to gateway/supply
function insulation acc. to DIN EN 50178, rated insulation voltage 50 V
eff
PROFIBUS PA/Supply
safe electrical isolation acc. to EN 50020, voltage peak value 375 V
Standard conformity
Electrical isolation
EN 50178, EN 50020
Electromagnetic compatibility
NAMUR NE 21
Protection degree
IEC/EN 60529
Fieldbus standard
IEC 61158-2, ISA S 50.02 Part 2
Climatic conditions
DIN IEC 721
Directive conformity
Electromagnetic compatibility
standards
Directive 89/336/EG
EN 61326, EN 50081-2
Ambient conditions
Classification 3K3
Ambient temperature
-20 ... 60 °C (253 ... 333 K)
Relative humidity
< 75 %
Degree of soiling
max. 2, according to IEC 664
Mechanical specifications
Connection type
terminals
Core cross-section
up to 2.5 mm
2
Housing
100 mm x 115 mm x 107 mm
Protection degree
IP20
Mass
650 g
Mounting
DIN rail mounting
Data for application in conjunction with
hazardous areas
EC-Type Examination Certificate
PTB 99 ATEX 2142
Group, category, type of protection,
Temperature classification
¬ II (1) G D [EEx ia] IIC
Statement of conformity
TÜV 00 ATEX 1531X
Group, category, type of protection,
Temperature classification
¬ II 3 G EEx nA IIC T4
Supply
Safety maximum voltage U
m
253 V AC / 125 V DC (Attention! U
m
is no rated voltage.)
Profibus PA
Voltage U
o
15 V
Current I
o
207,2
mA
Power
P
o
1,93 W
Safety maximum voltageU
m
60
V
Connection to gateway
Connection to the data interface CH1 ... CH4 of KLD2-GT-DP(R)-xPA (Konf. TÜV 02 ATEX
1819X)
Safety maximum voltageU
m
60 V (Attention! The rated voltage can be lower)
Directive conformity
standards
Directive 94/9 EU
EN 50014, EN 50020, EN 50021
