VEGA PROFIBUS PA T-Connector EEx (ia) - Manual (Page 4)

PROFIBUS PA
65
The measuring instruments are connected directly in the distributor via the EMC cable gland.
The screen is connected to the housing via the EMC cable gland.
A A A B B B S S S
19
58
64
Circuit diagram
Circuit diagram
A PA- (3)
S Shielding (4)
B PA+ (1)
n.c. (2)
A
A
A
S
S
S
B
B
B
Wire bridge
Enclosure
PROFIBUS-PA T-Connector EEx EMC version 1-way
Type FBCon PA CG 1way
A B S A B S A B S A B S
on
98
19
64
A PA- (3)
S Shielding (4)
B PA+ (1)
n.c. (2)
A
A A
A
S
S S
S
B
B B
B
Wire bridge
Enclosure
PROFIBUS-PA T-Connector EEx EMC version 2-way
Type FBCon PA CG 2way
Field-bus components for the area EEx (ia) with tension clamp connection
Ordering data
Type Cat. No.
Profibus PA T distributor type FBCon PA CG 2way EX 8564190000
Ordering data
Type Cat. No.
Profibus PA T distributor type FBCon PA CG 1way EX 8564180000
