Technical Data
Product name Features Order number
INSYS Modem 56k small EU 2.0 CTR21 11-02-01-01-42.002
INSYS Modem 56k small INT 2.0 standard countries 11-02-01-01-43.003
INSYS Modem 56k small INT 2.0 extended countries 11-02-01-01-43.004
INSYS Modem 56k small EU / INT
Network interface, line requirements analogue telephone network, dial-up line
Data transmission rate up to 56 kbps
Software update flash (INT), patch (EU)
Approvals R&TTE, CTR21
Country codes INSYS Modem 56k small EU: applicable in Europe (TBR 21)
INSYS Modem 56k small INT: worldwide compatible by the use of country codes
Standards developed according to CE directives manufactured according to ISO9002
Features
Configuration INSYS Modem 56k small EU: AT commands via serial line
INSYS Modem 56k small INT: AT commands via serial line, remote configuration
Connection auto answer mode, hardware/software handshake, autobauding,
fixed speed, sleep mode, number storage
Data format 10 and 11 bit: 7E1, 7O1, 7N2, 7E2, 7O2, 8N1, 8E1, 8O1, 8N2
and bit transparent
Protocols V.90, V.34+, V.34, V.32bis, V.32, V.23, V.22bis, V.22, V.21,
Bell Norm 103/212, Fax Class 1/2
Compression MNP 5, V.42bis LAPM, MNP 10, 10 EC, V.44
Error correction MNP 2/3/4and V.42
Safety functions INSYS Modem 56k small INT:
Security Callback, Security Callback to Caller (with Caller ID), password protected
data processing, selective call answer (with Caller ID)
Alarm functions INSYS Modem 56k small INT : SMS transmission per AT commands (Fax/Email)
Electrical specifications
Supply 10…32 VDC
Current consumption 140 mA
Application interface RS232, D-Sub 9 pin
Network interface RJ-12 Western plug
Physical specifications
Size (wxlxh) 23Ч110Ч75 mm
Temperature range 0…+55 °C
Humidity 0…95% non condensing
