KFD2-BR-Ex1.3PA.93
Accessories
Power Rail
UPR02
Power feed module KFD2-EB2
Terminal resistor KMD0-FT-Ex
Fx-FT-Ex1.I.IEC
Fx-FT-Ex1.D.IEC
Dimensions
Extendable lugs
Protective cap, remove for
power suppply via power rail
Power rail
100
93
107
115
