Status code Description according
to Profibus standard Possible cause
0 x 00 bad - non-specific Flash-Update active
0 x 04 bad - configuration error l Adjustment error
l Configuration error with PV-Scale (PV-Span too
small)
l Unit irregularity
l Error in the linearization table
0 x 0C bad - sensor failure l Hardware error
l Converter error
l Leakage pulse error
l Trigger error
0 x 10 bad - sensor failure l Measured value generation error
l Temperature measurement error
0 x 1f bad - out of service cons-
tant "O ut of Service" mode switched on
0 x 44 uncertain - last unstable
value Failsafe replacement value (Failsafe-Mode = "Last
value" and already valid measured value since swit-
ching on)
0 x 48 uncertain substitute set l Switch on simulation
l Failsafe replacement value (Failsafe-Mode = "Fsafe
value")
0 x 4c uncertain - initial value Failsafe replacement value (Failsafe-Mode = "Last valid
value" and no valid measured value since switching on)
0 x 51 uncertain - sensor; con-
version not accurate - low
limited Sensor value < lower limit
0 x 52 uncertain - sensor; con-
version not accurate - high
limited Sensor value > upper limit
0 x 80 good (non-cascade) - OK OK
0 x 84 good (non-cascade) - ac-
tive block alarm Static revision (FB, TB) changed (10 sec. active, after
the parameter of the static category has been written)
0 x 89 good (non-cascade) - ac-
tive advisory alarm - low
limited Lo-Alarm
0 x 8a good (non-cascade) - ac-
tive advisory alarm - high
limited Hi-Alarm
0 x 8d good (non-cascade) - ac-
tive critical alarm - low
limited Lo-Lo-Alarm
