11 .2 Communication Profibus PA
Instrument master file
The instrument master file (GSD) contains the characteristic data of the Profibus PA instrument.
These data are, e.g. the permissible transmission rates as well as information on diagnostics values
and the format of the measured value outputted by the PA instrument.
A bitmap file is also provided for the Profibus network planning tool. This file is installed automatically
when the GSD file is integrated. The bitmap file is used for symbolic indication of the PA instrument in
the configuration tool.
ID number
Each Profibus instrument gets an unambiguous ident number (ID number) from the Profibus user
organisation (PNO). This ID number is also included in the name of the GSD file. Optionally to this
manufacturer-specific GSD file, PNO provides also a general so-called profile-specific GSD file. If the
general GSD file is used, the sensor must be set to the profile-specific ident number via the DTM
software. By default, the sensor operates with the manufacturer-specific ID number. When using the
instruments on a segment coupler SK-2 or SK-3, a special GSD file must be used.
The following table shows the instrument ID and the GSD names for the VEGAPULS radar sensors.
Instrument
name Instrument ID GSD file name
VEGA Instrument
class in profile
3
.02
VEGA VEGA with
segment coup-
ler SK-2 or
SK-3 Profile-specific
VEGAPULS 61 0x0BFC 0x9702 PS 610BFC.GSD YP010BFC.GSD PA139702.GSD
VEGAPULS 62 0x0BFD 0x9702 PS 620BFD.GSD YP010BFD.GSD PA139702.GSD
VEGAPULS 63 0x0BFE 0x9702 PS 630BFE.GSD YP010BFE.GSD PA139702.GSD
VEGAPULS 65 0x0BFF 0x9702 PS 650BFF.GSD YP 010BFF.GSD PA 139702.GSD
VEGAPULS 66 0x0C00 0x9702 PS 660C00.GSD YP 010C00.GSD PA 139702.GSD
VEGAPULS 67 0x0C01 0x9702 PS 670C01.GSD YP 010C01.GSD PA 139702.GSD
VEGAPULS 68 0x0C02 0x9702 PS 680C02.GSD YP 010C02.GSD PA 139702.GSD
