121
,,,,,,,,,,,,,, QQQQQQQQQQQQQQ
MIDI Data Format
ROTARY SPEAKER (variation block)
No. Parameter Value
1 LFO Frequency 0.00Hz — 39.7Hz 0-127
2 LFO Depth 0 — 127 0-127
3
4
5
6
EQ Low Frequency 50Hz — 2.0kHz 8-40
7 EQ Low Gain –12 — +12dB 52-76
8 EQ High Frequency 500Hz — 16.0kHz 28-58
9 EQ High Gain –12 — +12dB 52-76
10 Dry/Wet D63 > W — D=W — D 1-127
11
12
13
14
15
16
TREMOLO (variation block)
No. Parameter Value
1 LFO Frequency 0.00Hz — 39.7Hz 0-127
2 AM Depth 0 — 127 0-127
3 PM Depth 0 — 127 0-127
4
5
6
EQ Low Frequency 50Hz — 2.0kHz 8-40
7 EQ Low Gain –12 — +12dB 52-76
8 EQ High Frequency 500Hz — 16.0kHz 28-58
9 EQ High Gain –12 — +12dB 52-76
10
11
12
13
14
LFO Phase Difference -180 — +180deg(resolution=3deg.) 4-124
15 Input Mode mono/stereo 0-1
16
AUTO PAN (variation block)
No. Parameter Value
1 LFO Frequency 0.00Hz — 39.7Hz 0-127
2 L/R Depth 0 — 127 0-127
3 F/R Depth 0 — 127 0-127
4 PAN Direction “L <-> R,L -> R,L <- R,Lturn,Rturn,L/R” 0-5
5
6
EQ Low Frequency 50Hz — 2.0kHz 8-40
7 EQ Low Gain –12 — +12dB 52-76
8 EQ High Frequency 500Hz — 16.0kHz 28-58
9 EQ High Gain –12 — +12dB 52-76
10
11
12
13
14
15
16
PHASER 1,2 (variation block)
No. Parameter Value
1 LFO Frequency 0.00Hz — 39.7Hz 0-127
2 LFO Depth 0 — 127 0-127
3 Phase Shift Offset 0 — 127 0-127
4 Feedback Level -63 — +63 1-127
5
6
EQ Low Frequency 50Hz — 2.0kHz 8-40
7 EQ Low Gain –12 — +12dB 52-76
8 EQ High Frequency 500Hz — 16.0kHz 28-58
9 EQ High Gain –12 — +12dB 52-76
10 Dry/Wet D63 > W — D=W — D 1-127
11 Stage 6 — 10(phaser1) / 3 — 5(phaser2) 3-10
12 Diffusion mono/stereo 0-1
13 LFO Phase Difference -180 — +180deg.(resolution=3deg.) 4-124
14
15
16
DISTORTION, OVERDRIVE (variation block)
No. Parameter Value
1 Drive 0 — 127 0-127
2 EQ Low Frequency 50Hz — 2.0kHz 8-40
3 EQ Low Gain –12 — +12dB 52-76
4 LPF Cutoff 1.0k — Thru 34-60
5 Output Level 0 — 127 0-127
6
7
EQ Mid Frequency 100Hz — 10.0kHz 23-54
8 EQ Mid Gain –12 — +12dB 52-76
9 EQ Mid Width 1.0 — 12.0 10-120
10 Dry/Wet D63 > W — D=W — D 1-127
11 Edge(Clip Curve) 0 — 127 0-127
12
13
14
15
16
AMP SIMULATOR (variation block)
No. Parameter Value
1 Drive 0 — 127 0-127
2 AMP Type “Off,Stack,Combo,Tube” 0-3
3 LPF Cutoff 1.0k — Thru 34-60
4 Output Level 0 — 127 0-127
5
6
7
8
9
10 Dry/Wet D63 > W — D=W — D 1-127
11 Edge(Clip Curve) 0 — 127 0-127
12
13
14
15
16
3BAND EQ(MONO) (variation block)
No. Parameter Value
1 EQ Low Gain –12 — +12dB 52-76
2 EQ Mid Frequency 100Hz — 10.0kHz 23-54
3 EQ Mid Gain –12 — +12dB 52-76
4 EQ Mid Width 1.0 — 12.0 10-120
5 EQ High Gain –12 — +12dB 52-76
6 EQ Low Frequency 50Hz — 2.0kHz 8-40
7 EQ High Frequency 500Hz — 16.0kHz 28-58
8
9
10
11
12
13
14
15
16
2BAND EQ(STEREO) (variation block)
No. Parameter Value
1 EQ Low Frequency 50Hz — 2.0kHz 8-40
2 EQ Low Gain –12 — +12dB 52-76
3 EQ High Frequency 500Hz — 16.0kHz 28-58
4 EQ High Gain –12 — +12dB 52-76
5
6
7
8
9
10
11
12
13
14
15
16
AUTO WAH (variation block)
No. Parameter Value
1 LFO Frequency 0.00Hz — 39.7Hz 0-127
2 LFO Depth 0 — 127 0-127
3 Cutoff Frequency Offset 0 — 127 0-127
4 Resonance 1.0 — 12.0 10-120
5
6
EQ Low Frequency 50Hz — 2.0kHz 8-40
7 EQ Low Gain –12 — +12dB 52-76
8 EQ High Frequency 500Hz — 16.0kHz 28-58
9 EQ High Gain –12 — +12dB 52-76
10 Dry/Wet D63 > W — D=W — D 1-127
11
12
13
14
15
16
