10 Supplement
10 .1 Technical data
General data
316L corresponds to 1.4404 or 1.4435, 316Ti corresponds to 1.4571
Materials
-
Housing plastic PBT, Alu die-casting, 316L
-
Inspection window in housing cover for
indicating and adjustment module Polycarbonate (UL-746-C listed)
-
Ground terminal 316Ti/316L
Weight 0.35 kg (0.772 lbs)
Supply circuit
Voltage supply and data transmission via the signal circuit
Voltage loss
-
at 4 mA approx. 3 V
-
at 20 mA approx. 2 V
Current range 3.5 … 22.5 mA 7)
Current increase with command/enquiry of
the VEGADIS 62 to the sensor ≤ 500 µA for approximately 20 ms, decay after e-
function
Overcurrent resistance 100 mA
Interpolation protection available, max. current 100 mA
Current measurement
Measuring range loop current 3.5 … 22.5 mA 8)
Deviation 9) ±0 .05 % of the span
Temperature coefficient 10) ±0 .1 % of the span/10 K
Interval 250 ms
Indicating and adjustment module
Display
-
Principle LCD
-
Measured value presentation 7 segments, 5-digit, height of digits 9 mm (0.354 in),
indication range -99999 … 99999
-
Bar graph 20 segments
-
Info line 14 segments, 6-digit, height of digits 5.5 mm
(0.217 in)
7) The indication remains dark if the loop current is not sufficient for operation.
8) For measured values outside the measuring range, an instructions is dis-
played instead of the measured value.
9) with reference temperature 20 °C
10) with reference temperature 20 °C
