9
CHEVROLET cont.
MAKE/MODEL YEARS INSTALLATION WIRE WIRE ANTENNA ANTENNA SPKR
KITS HARNESS HARNESS ADAPTER ADAPTER ACCESSORIES
INSTALLER PLUGS INTO PLUGS INTO AFTER AFTER GRILLS,
PREFERRED FACTORY FACTORY MARKET MARKET BRACKETS &
HARNESS RADIO ANTENNA TO ANTENNA TO ADAPTERS
FACTORY FACTORY
ANTENNA RADIO
CORVETTE 2009 N/A N/A N/A GM-A16 GM-A17
CRUZE 2011
EL CAMINO 69-77 N/R N/A N/A N/R N/R N/A
EL CAMINO 78-85 N/A GM-1342 GM-1341M N/R N/R N/A
EL CAMINO 86-88 GM-K8204/GM-K82041E= GM-1342 GM-1341M N/R N/R
EQUINOX (w/o OnStar) 05-06 GM-K0410P/GM-K0410DD# GM-1404 GM-1417M GM-A16 GM-A17
EQUINOX (w/ OnStar & Bose) 05-06 GM-K0410P/GM-K0410DD# N/A GM-A16 GM-A17
EQUINOX 07-09 GM-K0610DD#/GM-K0610DDP N/A CHR-A16 CHR-A17
EQUINOX 2011
EXPRESS VAN (fullsize) 96-00 GM-K9505 GM-1344 GM-1343M GM-A16 GM-A17 USPA-5060
EXPRESS VAN (fullsize) 01-02 GM-K9210P/GM-K9210DD# GM-1416 GM-1416-1M GM-A16 GM-A17 USPA-5060
EXPRESS VAN (fullsize) (w/o OnStar) 03-07 GM-K9210P/GM-K9210DD# N/A N/A GM-A16 GM-A17
EXPRESS VAN (fullsize) (w/ OnStar) 03-07 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17
EXPRESS VAN (w/o On Star) 08-11 GM-K0610DD#/GM-K0610DDP N/A N/A CHR-A16 CHR-A17
EXPRESS VAN (w/ OnStar & Bose) 08-11 GM-K0610DD#/GM-K0610DDP N/A CHR-A16 CHR-A17
HHR (w/o OnStar) 06-10 GM-K0410P/GM-K0410DD# GM-1406PIO+ GM-1405M+ CHR-A16 CHR-A17
HHR (w/ OnStar) 06-10 GM-K0410P/GM-K0410DD# N/A CHR-A16 CHR-A17
IMPALA 71-77 N/R N/A N/A N/R N/R SS-10
IMPALA 78-84 N/R GM-1342 GM-1341M N/R N/R SS-10
IMPALA 85-86 N/A GM-1342 GM-1341M N/R N/R SS-10
IMPALA 87-90 N/A GM-1342 GM-1341M N/R N/R SS-10
IMPALA 94-96 GM-K8204/GM-K82041E GM-1344 GM-1343M GM-A16 GM-A17
IMPALA (w/o OnStar) 00-05 GM-K9210P/GM-K9210DD# N/A N/A GM-A16 GM-A17
IMPALA (w/ OnStar w/o Bose) 00-05 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17
IMPALA (w/ OnStar w/ Bose) 00-05 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17
IMPALA (w/o OnStar) 06-11 GM-K0610DD#/GM-K0610DDP GM-1406+ GM-1405M+ CHR-A16 CHR-A17
IMPALA w/OnStar 06-11 GM-K0610DD#/GM-K0610DDP N/A CHR-A16 CHR-A17
KODIAK 94-96 N/A GM-1344 GM-1343M GM-A16 GM-A17
LUMINA 90-94 GM-K8204 GM-1344 GM-1343M GM-A16 GM-A17 SS-10
LUMINA 95-01 GM-K8204/GM-K82041E GM-1344 GM-1343M GM-A16 GM-A17
LUMINA VAN 90-96 GM-K8204 GM-1344 GM-1343M GM-A16 GM-A17
LUV TRUCK 73-84 N/A N/A N/A N/R N/R
MALIBU 73-77 N/A N/A N/A N/R N/R SS-10
MALIBU 78-84 N/A GM-1342 GM-1341M N/R N/R SS-10
MALIBU 97-00 GM-K8204/GM-K82041E GM-1344 GM-1343M GM-A16 GM-A17
MALIBU (w/o OnStar w/o Bose) 01-03 GM-K9210P/GM-K9210DD# GM-1404 GM-1417M GM-A16 GM-A17
MALIBU (w/ OnStar w/o Bose) 01-03 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17
MALIBU (w/ OnStar & w/ Bose) 01-03 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17
MALIBU (w/o OnStar) 04-07 GM-K0410P/GM-K0410DD# GM-1404 GM-1417M GM-A16 GM-A17
MALIBU (w/ OnStar) 04-07 GM-K0410P/GM-K0410DD# N/A GM-A16 GM-A17
MALIBU Classic (w/o OnStar) 2008 GM-K0410P/GM-K0410DD# N/A GM-A16 GM-A17
MALIBU Classic (w/ OnStar) 2008 GM-K0410P/GM-K0410DD# N/A GM-A16 GM-A17
MALIBU (w/o OnStar) 08-10 GM-K0410P/GM-K0410DD# N/A CHR-A16 CHR-A17
MALIBU (w/ OnStar) 08-10 GM-K0410P/GM-K0410DD# N/A CHR-A16 CHR-A17
MALIBU MAXX (w/o OnStar) 04-07 GM-K0410P/GM-K0410DD# GM-1404 GM-1417M GM-A16 GM-A17
MALIBU MAXX (w/ OnStar) 04-07 GM-K0410P/GM-K0410DD# N/A GM-A16 GM-A17
METRO 98-99 GM-K9210P ISU-1974 ISU-1975M N/R N/R
METRO 00-01 GM-K9210P GM-1416 GM-1416-1M GM-A16 GM-A17
MONTE CARLO 69-72 N/R N/A N/A N/R N/R SS-10
MONTE CARLO 73-77 N/R N/A N/A N/R N/R
MONTE CARLO 78-85 N/A GM-1342 GM-1341M N/R N/R SS-10
MONTE CARLO 86-88 GM-K8204 GM-1342 GM-1341M N/R N/R
MONTE CARLO 95-99 GM-K8204/GM-K82041E GM-1344 GM-1343M GM-A16 GM-A17
MONTE CARLO (w/o OnStar) 00-05 GM-K9210P/GM-K9210DD# N/A N/A GM-A16 GM-A17
MONTE CARLO (w/ OnStar w/o Bose) 00-05 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17
MONTE CARLO (w/ OnStar & w/ Bose) 00-05 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17
MONTE CARLO (w/o OnStar) 06-08 GM-K0610DD#/GM-K0610DDP GM-1406+ GM-1405M+ CHR-A16 CHR-A17
MONTE CARLO (w/ OnStar) 06-08 GM-K0610DD#/GM-K0610DDP N/A CHR-A16 CHR-A17
MONZA 75-77 N/R N/A N/A N/R N/R
MONZA 78-81 N/R GM-1342 GM-1341M N/R N/R
NOVA 67-77 N/R N/A N/A N/R N/R SS-10
NOVA 78-80 N/R GM-1342 GM-1341M N/R N/R SS-10
NOVA 85-88 GM-K8204 GM-1342 GM-1341M N/R N/R
PICKUP (fullsize) 73-77 N/A N/A N/A N/R N/R N/A
PICKUP (fullsize) 78-87 N/A GM-1342 GM-1341M N/R N/R N/A
PICKUP (fullsize) 88-94 N/A GM-1344 GM-1343M GM-A16 GM-A17
PRISM 98-99 TOY-K9302P ISU-1974 ISU-1975M N/R N/R
PRISM 00-02 TOY-K9302P GM-1416 GM-1416-1M GM-A16 GM-A17
SILVERADO (w/o OnStar) 95-02 GM-K9505 GM-1344* GM-1343M GM-A16 GM-A17 GSA-FT5465
SILVERADO (w/ OnStar) 95-02 GM-K9505 GM-1344* GM-1343M GM-A16 GM-A17 GSA-FT5465
* This harness works on standard wiring only.
Not for amplified,JBL, or premium sound systems.
** Works on standard wiring systems only.
Not for vehicles with Bose or On-Star systems.
< Requires factory mounting bracket.
# Fits Double Din or two Single ISO mount radios.
^ Requires locating a switched 12v< power source for
after-market radios.
