wiRiNG hARNEssEs

suB-1924

SUBARU

90-UP

> Plugs into factory harness

Power / 4 Speakers

S # H442

MiT-1644

MITSUBISHI

07-UP

• Plugs into Factory Harness

S # H651

sMA-22100

SMART CAR

08-UP

• Plugs into Factory Harness

S # H654

Nis-1708

NISSAN

07-UP

• Plugs into Factory Harness

S # H490

MiT-1645M

MITSUBISHI

07-UP (male plug)

• Plugs into Factory Radio

S # H652

Nis-1705M

NISSAN

07-UP (male plug)

• Plugs into Factory Radio

S # H653

MAZ-1857M

MAZDA

89-02 (male plug)

• Plugs into Factory Radio

S # H648

MAZ-1858

MAZDA

01-UP

• Plugs into Factory Harness

S # H649

MAZ-1859M

MAZDA

01-UP (male plug)

• Plugs into Factory Radio

S # H650

Nis-1700

NISSAN

84-94

• Plugs into factory harness

Power / 4 Speakers

S # H420

Nis-1701M

NISSAN

84-94

• Plugs into factory radio

Power / 4 Speakers (MALE PLUGS)

S # H423

Nis-1702

NISSAN

95-UP

• Plugs into factory harness

Power / 4 Speakers

S # H421

Nis-1703M

NISSAN

95-UP

• Plugs into factory radio

Power / 4 Speakers (MALE PLUG)

S # H422

Nis-4700

NISSAN / INFINITY

87-94

(premium sound)

• Plugs into car harness at radio

S # H476

Nis-4702

NISSAN / INFINITY

95-UP

(premium sound)

• Plugs into factory harness

S # H477

MAZDA. MITSUBISHI. NISSAN. SMARTCAR. SUBARU
