13
DODGE cont.
MAKE/MODEL YEARS INSTALLATION WIRE WIRE ANTENNA ANTENNA SPKR
KITS HARNESS HARNESS ADAPTER ADAPTER ACCESSORIES
INSTALLER PLUGS INTO PLUGS INTO AFTER AFTER GRILLS,
PREFERRED FACTORY FACTORY MARKET MARKET BRACKETS &
HARNESS RADIO ANTENNA TO ANTENNA TO ADAPTERS
FACTORY FACTORY
ANTENNA RADIO
MONACO 90-92 N/A JP-1622 JP-1623M N/R N/R USPA-6090
NEON 95-99 CHR-K7401/CF-K7401 CHR-1634 CHR-1633M N/R N/R USPA-5060
NEON 00-01 CHR-K9807 CHR-1634 CHR-1633M N/R N/R USPA-5060
NEON 02-01 CHR-K9807 CHR-1638 CHR-1637M CHR-A16 CHR-A17 USPA-5060
NITRO 07-11 CHR-K0710B#/CHR-K0710P CHR-1642* CHR-1641M* EURO-A106 EURO-A107
NEWPORT 69-74 N/R N/A N/A N/R N/R USPA-6090
NEWPORT 75-83 CHR-K7401/CF-K7401 N/A N/A N/R N/R USPA-6090
OMNI 78-83 CHR-K7401/CF-K7401 N/A N/A N/R N/R N/A
OMNI 84-90 CHR-K7401/CF-K7401 CHR-1634 CHR-1633M N/R N/R N/A
PICKUP (fullsize) 74-93 CHR-K7401/CF-K7401 CHR-1634 CHR-1633M N/R N/R
RAIDER 87-89 N/A CI-1610 N/A N/R N/R
RAM 50 87-94 N/A CI-1610 N/A N/R N/R
RAM CHARGER 74-80 CHR-K7401/CF-K7401 N/A N/A N/R N/R
RAM CHARGER 81-83 CHR-K7401/CF-K7401 N/A N/A N/R N/R
RAM CHARGER 84-93 CHR-K7401/CF-K7401 N/A N/A N/R N/R
RAM PICKUP 94-01 CHR-K7401/CF-K7401 CHR-1634 CHR-1633M N/R N/R USPA-6090
RAM PICKUP 02-05 CHR-K9807 CHR-1638* CHR-1637M CHR-A16 CHR-A17
RAM PICKUP (w/factory Nav) 06-08 CHR-K0408DD# CHR-1638*^ CHR-1637M CHR-A16 CHR-A17
RAM PICKUP (w/o factory amp) 06-08 CHR-K0410P CHR-1638*^ CHR-1637M CHR-A16 CHR-A17
RAM PICKUP (w/ factory amp) 06-08 CHR-K0410P CHR-1637M CHR-A16 CHR-A17
RAM PICKUP (w/o factory amp) 09-11 CHR-K0710B#/CHR-K0710P CHR-1642* CHR-1641M EURO-A106 EURO-A107
RAM PICKUP (w/ factory amp) 09-11 CHR-K0710B#/CHR-K0710P N/A EURO-A106 EURO-A107
RAMPAGE 82-83 CHR-K7401/CF-K7401 N/A N/A N/R N/R
RAMPAGE 84-87 CHR-K7401/CF-K7401 N/A N/A N/R N/R
RELIANT K 77-80 N/R N/A N/A N/R N/R USPA-6090
RELIANT K 81-83 CHR-K7401/CF-K7401 N/A N/A N/R N/R USPA-6090
RELIANT K 84-89 CHR-K7401/CF-K7401 N/A N/A N/R N/R USPA-6090
SHADOW 87-94 CHR-K7401/CF-K7401 CHR-1634 CHR-1633M N/R N/R USPA-6090
SPIRIT 89-95 CHR-K7401/CF-K7401 CHR-1634 CHR-1633M N/R N/R USPA-6090
SPRINTER 03-06 N/A N/A VW-A18 VW-A17
SPRINTER (w/base model radio) 07-10 EURO-11010 EURO-11009M EURO-A106 EURO-A107
SPRINTER (w/factory Nav) 07-10 N/A
STEALTH 91-96 N/A CI-1610 N/A N/R N/R USPA-6090
STRATUS 95-00 CHR-K7401/CF-K7401 CHR-1634 CHR-1633M N/R N/R USPA-5090
STRATUS 2001 CHR-K9807 CHR-1634 CHR-1633M N/R N/R
STRATUS 02-06 CHR-K9807 CHR-1638 CHR-1637M CHR-A16 CHR-A17
ST. REGIS 79-81 CHR-K7401/CF-K7401 N/A N/R N/R USPA-6090
SUNDANCE 87-94 CHR-K7401/CF-K7401 CHR-1634 CHR-1633M N/R N/R
RAM VAN (fullsize) 78-83 CHR-K7401 N/A N/A N/R N/R
RAM VAN (fullsize) 84-89 CHR-K7401 N/A N/A N/R N/R
RAM VAN (fullsize) 90-93 CHR-K7401/CF-K7401 CHR-1634 CHR-1633M N/R N/R
RAM VAN (fullsize) 94-01 CHR-K7401/CF-K7401 CHR-1634 CHR-1633M N/R N/R USPA-6090
RAM VAN (fullsize) 02-03 CHR-K9807 CHR-1638 CHR-1637M CHR-A16 CHR-A17
VIPER 93-01 CHR-K7401 CHR-1634 CHR-1633M N/R N/R
VIPER 02-08 CHR-K9807 CHR-1638 CHR-1637M CHR-A16 CHR-A17
EAGLE
MAKE/MODEL YEARS INSTALLATION WIRE WIRE ANTENNA ANTENNA SPKR
KITS HARNESS HARNESS ADAPTER ADAPTER ACCESSORIES
INSTALLER PLUGS INTO PLUGS INTO AFTER AFTER GRILLS,
PREFERRED FACTORY FACTORY MARKET MARKET BRACKETS &
HARNESS RADIO ANTENNA TO ANTENNA TO ADAPTERS
FACTORY FACTORY
ANTENNA RADIO
MEDALLION 88-89 N/A N/A N/A N/R N/R
PREMIER 88-92 N/A JP-1622 JP-1623M N/R N/R USPA-6090
SUMMIT 89-92 N/A CI-1610 N/A N/R N/R
SUMMIT 93-96 N/A CI-1610 N/A N/R N/R USPA-5090
SUMMIT WAGON 92-94 N/A CI-1610 N/A N/R N/R
TALON 90-94 N/A CI-1610 N/A N/R N/R USPA-5090
TALON 95-98 N/A CI-1612 CI-1613M N/R N/R USPA-5090/USPA-6090
VISION 93-97 CHR-K7401/CF-K7401 CHR-1634 CHR-1633M N/R N/R USPA-6090
* This harness works on standard wiring only.
Not for amplified,JBL, or premium sound systems.
** Works on standard wiring systems only.
Not for vehicles with Bose or On-Star systems.
< Requires factory mounting bracket.
# Fits Double Din or two Single ISO mount radios.
^ Requires locating a switched 12v< power source for
after-market radios.
