10
CHEVROLET cont.
MAKE/MODEL YEARS INSTALLATION WIRE WIRE ANTENNA ANTENNA SPKR
KITS HARNESS HARNESS ADAPTER ADAPTER ACCESSORIES
INSTALLER PLUGS INTO PLUGS INTO AFTER AFTER GRILLS,
PREFERRED FACTORY FACTORY MARKET MARKET BRACKETS &
HARNESS RADIO ANTENNA TO ANTENNA TO ADAPTERS
FACTORY FACTORY
ANTENNA RADIO
SILVERADO (w/ OnStar & w/ Bose) 95-02 GM-K9505 GM-1344* GM-1343M GM-A16 GM-A17 GSA-FT5465
SILVERADO (w/o OnStar) 03-06 GM-K9210P/GM-K9210DD# N/A N/A GM-A16 GM-A17 GSA-FT5465
SILVERADO (w/ OnStar) 03-06 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17 GSA-FT5465
SILVERADO (w/ OnStar & w/ Bose) 03-06 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17 GSA-FT5465
SILVERADO CLASSIC 2007 GM-K9210P/GM-K9210DD# N/A N/A GM-A16 GM-A17
SILVERADO (NEW BODY STYLE) 07-11 GM-K0610DD#/GM-K0610DDP GM-1406+ GM-A16 GM-A17 GSA-FT5465
SILVERADO (w/ OnStar) 2007 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17
SILVERADO (w/ OnStar & w/ Bose) 2007 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17
SILVERADO (w/o OnStar & w/o Bose) 07-10 N/A GM-1406+ GM-1405M+ CHR-A16 CHR-A17
SILVERADO (w/o OnStar) 07-10 N/A N/A CHR-A16 CHR-A17
SILVERADO (w/ OnStar & w/ Bose) 07-10 N/A N/A CHR-A16 CHR-A17
SPECTRUM 85-88 N/A ISU-1974 ISU-1975M N/R N/R
SPRINT 85-88 DIN MOUNT ISU-1974 ISU-1975M N/R N/R
SSR 03-06 GM-K9210P/GM-K9210DD# N/A N/A GM-A16 GM-A17
SSR (w/ OnStar & w/o Bose) 03-06 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17
SSR (w/ OnStar & w/ Bose) 03-06 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17
SUBURBAN 73-77 N/A N/A N/A N/R N/R N/A
SUBURBAN 78-88 N/A GM-1342 GM-1341M N/R N/R N/A
SUBURBAN 89-91 GM-K8204 GM-1344 GM-1343M GM-A16 GM-A17
SUBURBAN 92-94 N/A GM-1344 GM-1343M GM-A16 GM-A17
SUBURBAN (w/o OnStar) 95-02 GM-K9505 GM-1344+ GM-1343M GM-A16 GM-A17 GSA-FT5465
SUBURBAN (w/ OnStar) 95-02 GM-K9505 GM-1343M GM-A16 GM-A17 GSA-FT5465
SUBURBAN (w/ OnStar & w/ Bose) 95-02 GM-K9505 GM-1343M GM-A16 GM-A17 GSA-FT5465
SUBURBAN (w/o OnStar) 03-06 GM-K9210P/GM-K9210DD N/A N/A GM-A16 GM-A17 GSA-FT5465
SUBURBAN (w/ OnStar & w/o Bose) 03-06 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17 GSA-FT5465
SUBURBAN (w/ OnStar & w/ Bose) 03-06 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17 GSA-FT5465
SUBURBAN (w/o OnStar) 07-11 GM-K0610DD#/GM-K0610DDP GM-1406+ GM-1405M+ CHR-A16 CHR-A17
SUBURBAN (w/ OnStar) 07-11 GM-K0610DD#/GM-K0610DDP N/A CHR-A16 CHR-A17
S-10 pickup 82-89 GM-K82041E GM-1342 GM-1341M N/R N/R N/A
S-10 pickup 90-93 GM-K82041E GM-1344 GM-1343M GM-A16 GM-A17 N/A
S-10 pickup 94-97 N/A GM-1344 GM-1343M GM-A16 GM-A17 N/A
S-10 pickup 98-01 GM-K8204/GM-K82041E GM-1344 GM-1343M GM-A16 GM-A17 N/A
S-10 pickup (standard radio) 2002 GM-K8204/GM-K82041E GM-1344 GM-1343M GM-A16 GM-A17 N/A
S-10 pickup (oversized radio) w/o OnStar 02-04 GM-K9210P/GM-K9210DD# GM-1416 GM-1415M GM-A16 GM-A17 N/A
S-10 pickup (w/ OnStar) 02-04 GM-K9210P/GM-K9210DD# GM-1416 GM-1415M GM-A16 GM-A17 N/A
S-10 pickup (w/ OnStar & w/ Bose) 02-04 GM-K9210P/GM-K9210DD# GM-1416 GM-1415M GM-A16 GM-A17 N/A
TAHOE (w/o OnStar or amp) 95-02 GM-K9505/GM-K8205P GM-1344+ GM-1343M GM-A16 GM-A17 GSA-FT5465
TAHOE (w/ OnStar & w/o Bose) 95-02 GM-K9505/GM-K8205P GM-1344+ GM-1343M GM-A16 GM-A17 GSA-FT5465
TAHOE (w/ OnStar & w/ Bose) 95-02 GM-K9505/GM-K8205P GM-1344+ GM-1343M GM-A16 GM-A17 GSA-FT5465
TAHOE (w/o OnStar) 03-06 GM-K9210P/GM-K9210DD# N/A N/A GM-A16 GM-A17 GSA-FT5465
TAHOE (w/ OnStar & w/o Bose) 03-06 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17 GSA-FT5465
TAHOE (w/ OnStar & w/ Bose) 03-06 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17 GSA-FT5465
TAHOE (w/o OnStar) 07-11 GM-K0610DD#/GM-K0610DDP GM-1406+ GM-1405M+ CHR-A16 CHR-A17
TAHOE (w/OnStar) 07-11 GM-K0610DD#/GM-K0610DDP N/A CHR-A16 CHR-A17
TRACKER 1998 GM-K9210P/GM-K9211P ISU-1974 ISU-1975M N/R N/R
TRACKER 1999 GM-K9210P/GM-K9211P ISU-1974 ISU-1975M N/R N/R USPA-5060
TRACKER 00-04 GM-K9210P/GM-K9211P GM-1416 GM-1406-1M N/R N/R USPA-5060
TRAILBLAZER (w/o OnStar) 02-09 GM-K9210P/GM-K9210DD# N/A N/A GM-A16 GM-A17
TRAILBLAZER (w/ OnStar & w/o Bose) 02-09 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17
TRAILBLAZER (w/ OnStar & w/ Bose) 02-09 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17
TRAVERSE (w/o OnStar) 09-11 GM-K0610DD#/GM-K0610DDP N/A CHR-A16 CHR-A17
TRAVERSE (w/ OnStar) '09-11 GM-K0610DD#/GM-K0610DDP N/A CHR-A16 CHR-A17
UPLANDER (w/o OnStar) 05-08 GM-K0510DDP/GM-K0510DD N/A N/A GM-A16 GM-A17
UPLANDER (w/ OnStar) 05-08 GM-K0510DDP/GM-K0510DD N/A GM-A16 GM-A17
VAN (fullsize) 71-77 N/R N/A N/A N/R N/R
VAN (fullsize) 78-87 N/R GM-1342 GM-1341M N/R N/R
VAN (fullsize) 88-95 GM-K8204 GM-1344 GM-1343M GM-A16 GM-A17
VEGA 71-77 N/R N/A N/A N/R N/R
VENTURE VAN (w/o OnStar) 97-99 GM-K8204/GM-K82041E GM-1344 GM-1343M GM-A16 GM-A17 USPA-5060
VENTURE VAN (w/ OnStar) 97-99 GM-K8204/GM-K82041E GM-1344 GM-1343M GM-A16 GM-A17 USPA-5060
VENTURE VAN (w/ OnStar & w/ Bose) 97-99 GM-K8204/GM-K82041E GM-1344 GM-1343M GM-A16 GM-A17 USPA-5060
VENTURE VAN 01-02 GM-K9210P/GM-K9210DD# GM-1416 GM-1406-1M GM-A16 GM-A17 USPA-5060
VENTURE VAN (w/o OnStar) 2000 GM-K9210P/GM-K9210DD# GM-1416 GM-1406-1M GM-A16 GM-A17 USPA-5060
VENTURE VAN (w/ OnStar & w/ Bose) 2000 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17 USPA-5060
VENTURE VAN (w/o OnStar) 03-05 GM-K9210P/GM-K9210DD# GM-1416 GM-1406-1M GM-A16 GM-A17 USPA-5060
VENTURE VAN (w/ OnStar) 03-05 GM-K9210P/GM-K9210DD# GM-1416 GM-1406-1M GM-A16 GM-A17 USPA-5060
VENTURE VAN (w/ OnStar & w/ Bose) 03-05 GM-K9210P/GM-K9210DD# N/A GM-A16 GM-A17 USPA-5060
* This harness works on standard wiring only.
Not for amplified,JBL, or premium sound systems.
** Works on standard wiring systems only.
Not for vehicles with Bose or On-Star systems.
< Requires factory mounting bracket.
# Fits Double Din or two Single ISO mount radios.
^ Requires locating a switched 12v< power source for
after-market radios.
