14
FORD
MAKE/MODEL YEARS INSTALLATION WIRE WIRE ANTENNA ANTENNA SPKR
KITS HARNESS HARNESS ADAPTER ADAPTER ACCESSORIES
INSTALLER PLUGS INTO PLUGS INTO AFTER AFTER GRILLS,
PREFERRED FACTORY FACTORY MARKET MARKET BRACKETS &
HARNESS RADIO ANTENNA TO ANTENNA TO ADAPTERS
FACTORY FACTORY
ANTENNA RADIO
AEROSTAR 85-91 CF-K7401 FD-1594 FD-1593M N/R N/R N/A
AEROSTAR 92-97 DIN MOUNT FD-1594 FD-1593M N/R N/R N/A
ASPIRE 94-97 DIN MOUNT FD-1594 FD-1593M N/R N/R
BRONCO 73-79 N/A N/A N/A N/R N/R
BRONCO 80-82 N/A N/A N/A N/R N/R
BRONCO 83-86 N/A FD-1592 N/A N/R N/R N/A
BRONCO 87-91 N/A FD-1594* FD-1593M N/R N/R N/A
BRONCO 92-96 DIN MOUNT FD-1594 FD-1593M N/R N/R USPA-6090
BRONCO II 83-85 CF-K7401 FD-1592 N/A N/R N/R USPA-6090
BRONCO II 86-88 CF-K7401 FD-1594 FD-1593M N/R N/R USPA-6090
BRONCO II 89-92 DIN MOUNT FD-1594* FD-1593M N/R N/R USPA-6090
CONTOUR 95-00 DIN MOUNT FD-1594* FD-1593M N/R N/R USPA-6090
COURIER 73-82 N/R N/A N/A N/R N/R
CROWN VICTORIA 79-82 CF-K7401 N/A N/A N/R N/R USPA-6090
CROWN VICTORIA 83-85 CF-K7401 FD-1592 N/A N/R N/R
CROWN VICTORIA 86-89 CF-K7401 FD-1594 FD-1593M N/R N/R
CROWN VICTORIA 90-94 DIN MOUNT FD-1594 FD-1593M N/R N/R USPA-6090
CROWN VICTORIA 95-97 FM-K9510P FD-1596 FD-1595M FD-A16 FD-A17 USPA-6090
CROWN VICTORIA 98-02 FM-K9510P FD-1598 FD-1597M FD-A16 FD-A17 USPA-6090
CROWN VICTORIA 03-09 FM-K9510P FD-5520 FD-5521M N/A N/A USPA-6090
ECONOLINE VAN 71-74 N/R N/A N/A N/R N/R
ECONOLINE VAN 75-86 N/A FD-1592 N/A N/R N/R
ECONOLINE VAN 87-91 FD-K5510 FD-1594 FD-1593M N/R N/R
ECONOLINE VAN/CLUBWGN 92-96 DIN MOUNT FD-1594 FD-1593M N/R N/R USPA-6090
ECONOLINE VAN/CLUBWGN 1997 FM-K9510P/FM-K9510DD# FD-1594 FD-1593M N/R N/R USPA-6090
ECONOLINE VAN/CLUBWGN 98-08 FM-K9510P/FM-K9510DD# FD-1598 FD-1597M N/R N/R USPA-6090
ECONOLINE 09-10 FM-K0411P/FM-K0411DD# FD-5520 FD-5521M CHR-A16 CHR-A17
EDGE 07-10 FM-K0411P/FM-K0411DD# FD-5520* FD-5521M CHR-A16 CHR-A17 USPA-6090
ESCAPE 01-07 FM-K9510P/FM-K9510DD# FD-1598 FD-1597M N/R USPA-6090
ESCAPE flatblack (FB) 08-11 FM-K0811DDB/FM-K0811PB FD-45520* FD-5521M CHR-A16 CHR-A17 USPA-6090
ESCAPE silver (S) 08-10 FM-K0811DDS/FM-K0811PS FD-45520* FD-5521M CHR-A16 CHR-A17 USPA-6090
ESCAPE (w/Nav) 06-07 FM-K9510P FD-1594 FD-1593M USPA-6090
ESCORT 81-83 N/A N/A N/A N/R N/R N/A
ESCORT 84-85 N/A FD-1592 N/A N/R N/R N/A
ESCORT 86-90 N/A FD-1594 FD-1593M N/R N/R N/A
ESCORT 91-96 DIN MOUNT FD-1594 FD-1593M N/R N/R USPA-6090
ESCORT 97-03 N/A FD-1593M FD-A16 FD-A17 USPA-6090
EXCURSION 00-05 FM-K9510P/FM-K9510DD# FD-1598 FD-1597M N/R N/R USPA-6090
EXPEDITION 1997 N/A FD-1596 FD-1595M FD-A16 FD-A17 USPA-6090
EXPEDITION 98-02 FM-K9510P FD-1598* FD-1597M N/R N/R USPA-6090
EXPEDITION (early production) 2003 FM-K9510P/FM-K0106DD# FD-1600* FD-1597M N/R N/R USPA-6090
EXPEDITION 03-06 FM-K9510P/FM-K0106DD# FD-5520* N/A N/R N/R USPA-6090
EXPEDITION (w/ Factory Nav) 07-10 FM-K0411P/FM-K0411DD# FD-45520* N/A CHR-A16 CHR-A17 USPA-6090
EXPLORER 91-94 DIN MOUNT FD-1594 FD-1593M N/R N/R USPA-6090
EXPLORER 95-97 FM-K9510P/FM-K9510DD# FD-1596* N/A FD-A16 FD-A17 USPA-6090
EXPLORER 98-05 FM-K9510P/FM-K9510DD# FD-1598* FD-1597M FD-A16 FD-A17 USPA-6090
EXPLORER 2 door 02-05 FM-K9510P/FM-K9510DD# FD-1598* FD-1597M FD-A16 FD-A17 USPA-6090
EXPLORER 4 door 2005 FM-K9510P/FM-K0106DD# FD-45520 N/A N/R N/R USPA-6090
EXPLORER 06-10 FM-K0411P/FM-K0411DD# FD-45520 N/A CHR-A16 CHR-A17 USPA-6090
EXPLORER SPORT TRAC 00-06 FM-K9510P/FM-K0106DD# FD-1598* FD-1597M N/R N/R USPA-6090
EXPLORER SPORT TRAC 07-09 FM-K0411P/FM-K0411DD# FD-45520 N/A CHR-A16 CHR-A17 USPA-6090
FAIRMONT 78-81 N/A N/A N/A N/R N/R
FAIRMONT 82-83 N/A FD-1592 N/A N/R N/R
FESTIVA 88-93 N/A N/A N/A N/R N/R
FIESTA 78-83 N/A N/A N/A N/R N/R
FLEX 09-10 N/A CHR-A16 CHR-A17 USPA-6090
FOCUS 00-04 FD-K9804P FD-1594 FD-1593M VW-A16L VW-A17 USPA-6090
FOCUS (w/Blaupunkt radio) 03-04 FD-K9804P VW-11000 VW-12000M VW-A18 VW-A17 USPA-6090
FOCUS 05-07 FM-K0411P/FM-K0411DD# FD-5520 FD-5521M N/R N/R USPA-6090
FOCUS 08-10 N/A CHR-A16 CHR-A17 USPA-6090
FUSION 06-09 FM-K0411P/FM-K0411DD# FD-5520 FD-5521M CHR-A16 CHR-A17 USPA-6090
FUSION 2010 N/A CHR-A16 CHR-A17 USPA-6090
500 05-07 FM-K0411P/FM-K0411DD# FD-5520 N/A N/R N/R USPA-6090
FREESTAR 04-07 FM-K0411P/FM-K0411DD# FD-45520 N/A N/R N/R USPA-6090
FREESTYLE 05-07 FM-K0411P/FM-K0411DD# FD-45520 N/A N/R N/R
FUTURA 82-83 N/A N/A N/A N/R N/R USPA-6090
GALAXY 73-78 N/R N/A N/A N/R N/R
GRANADA 81-82 N/A N/A N/A N/R N/R N/A
* This harness works on standard wiring only.
Not for amplified,JBL, or premium sound systems.
** Works on standard wiring systems only.
Not for vehicles with Bose or On-Star systems.
< Requires factory mounting bracket.
# Fits Double Din or two Single ISO mount radios.
^ Requires locating a switched 12v< power source for
after-market radios.
