GMC

MAKE/MODEL

YEARS

INSTALLATION

WIRE

WIRE

ANTENNA

ANTENNA

SPKR

KITS

HARNESS

HARNESS

ADAPTER

ADAPTER

ACCESSORIES

INSTALLER

PLUGS INTO

PLUGS INTO

AFTER

AFTER

GRILLS,

PREFERRED

FACTORY

FACTORY

MARKET

MARKET

BRACKETS &

HARNESS

RADIO

ANTENNA TO

ANTENNA TO

ADAPTERS

FACTORY

FACTORY

ANTENNA

RADIO

ACADIA (w/o OnStar)

07-11

GM-K0610DD#/GM-K0610DDP

GM-1406+

CHR-A16

CHR-A17

ACADIA (w/ OnStar)

07-11

GM-K0610DD#/GM-K0610DDP

CANYON (w/o OnStar & no amp)

04-10

GM-K9210P/GM-K9210DD#

N/A

N/A

GM-A16

GM-A17

CANYON (w/o OnStar)

04-10

GM-K9210P/GM-K9210DD#

N/A

GM-A16

GM-A17

CANYON (w/ OnStar)

04-10

GM-K9210P/GM-K9210DD#

N/A

GM-A16

GM-A17

CREW CAB DUALLY

89-91

GM-K8204

GM-1342

GM-1341M

N/R

N/R

CREW CAB DUALLY

92-94

N/A

GM-1344

GM-1343M

GM-A16

GM-A17

ENVOY

98-01

GM-K8204

GM-1344

GM-1343M

GM-A16

GM-A17

ENVOY (w/o OnStar & no amp)

02-08

GM-K9210P/GM-K9210DD#

N/A

N/A

GM-A16

GM-A17

ENVOY (w/ OnStar & w/ amp)

02-08

GM-K9210P/GM-K9210DD#

N/A

GM-A16

GM-A17

ENVOY (w/ OnStar & w/ Bose amp)

02-08

GM-K9210P/GM-K9210DD#

N/A

GM-A16

GM-A17

JIMMY (fullsize)

73-77

N/A

N/A

N/A

N/R

N/R

N/A

JIMMY (fullsize)

78-87

N/A

GM-1342

GM-1341M

N/R

N/R

N/A

JIMMY (fullsize)

89-91

GM-K8204

GM-1344

GM-1343M

GM-A16

GM-A17

JIMMY (S-15)

82-89

GM-K82041E

GM-1342

GM-1341M

N/R

N/R

N/A

JIMMY (S-15)

90-93

GM-K82041E

GM-1344

GM-1343M

GM-A16

GM-A17

N/A

JIMMY (S-15)

1994

GM-K8204

GM-1344

GM-1343M

GM-A16

GM-A17

JIMMY (S-15)

95-97

N/A

GM-1344

GM-1343M

GM-A16

GM-A17

N/A

JIMMY

98-01

GM-K8204/GM-K82041E

GM-1344

GM-1343M

GM-A16

GM-A17

N/A

JIMMY (standard radio)

2002

GM-K8204/GM-K82041E

GM-1344

GM-1343M

GM-A16

GM-A17

N/A

JIMMY (oversized radio)

02-03

GM-K9210P/GM-K9210DD#

GM-1416

GM-1416-1M

GM-A16

GM-A17

N/A

PICKUP SIERRA (fullsize)

73-77

N/A

N/A

N/A

N/R

N/R

N/A

PICKUP SIERRA (fullsize)

78-87

N/A

GM-1342

GM-1341M

N/R

N/R

N/A

PICKUP SIERRA (fullsize)

88-94

N/A

GM-1344

GM-1343M

GM-A16

GM-A17

PICKUP SIERRA (w/o OnStar & w/o amp)

95-02

GM-K9505

GM-1344

GM-1343M

GM-A16

GM-A17

GSA-FT5465

PICKUP SIERRA (w/ OnStar)

95-02

GM-K9505

GM-1344

GM-1343M

GM-A16

GM-A17

GSA-FT5465

PICKUP SIERRA (w/ OnStar & w/o Bose)

95-02

GM-K9505

GM-1344

GM-1343M

GM-A16

GM-A17

GSA-FT5465

PICKUP SIERRA (w/o OnStar)

03-06

GM-K9210P/GM-K9210DD#

N/A

N/A

GM-A16

GM-A17

GSA-FT5465

PICKUP SIERRA (w/ OnStar)

03-06

GM-K9210P/GM-K9210DD#

N/A

GM-A16

GM-A17

PICKUP SIERRA (w/ OnStar & w/ Bose)

03-06

GM-K9210P/GM-K9210DD#

N/A

GM-A16

GM-A17

PICKUP SIERRA (Classic)(w/o OnStar)

2007

GM-K9210P/GM-K9210DD#

N/A

N/A

GM-A16

GM-A17

GSA-FT5465

PICKUP SIERRA (Classic)(w/ OnStar)

2007

GM-K9210P/GM-K9210DD#

N/A

GM-A16

GM-A17

PICKUP SIERRA (Classic)(w/ OnStar/Bose)

2007

N/A

N/A

GM-A16

GM-A17

PICKUP SIERRA (w/o OnStar w/o amp)

07-11

GM-K0610DD#/GM-K0610DDP

N/A

N/A

CHR-A16

CHR-A17

PICKUP SIERRA (w/ OnStar w/ Bose)

07-11

GM-K0610DD#/GM-K0610DDP

N/A

CHR-A16

CHR-A17

SAFARI VAN

85-89

GM-K82041E

GM-1342

GM-1341M

N/R

N/R

SAFARI VAN

90-91

GM-K82041E

GM-1342

GM-1341M

N/R

N/R

USPA-5060

SAFARI VAN

92-95

GM-K82041E

GM-1344

GM-1343M

GM-A16

GM-A17

USPA-5060

SAFARI VAN

96-05

GM-K9505

GM-1344

GM-1343M

GM-A16

GM-A17

USPA-5060

S-15 PICKUP

82-90

GM-K82041E

GM-1342

GM-1341M

N/R

N/R

SONOMA

1991

GM-K82041E

GM-1342

GM-1341M

N/R

N/R

SONOMA

92-93

GM-K82041E

GM-1344

GM-1343M

GM-A16

GM-A17

SONOMA

94-97

N/A

GM-1344

GM-1343M

GM-A16

GM-A17

N/A

SONOMA

98-01

GM-K8204/GM-K82041E

GM-1344

GM-1343M

GM-A16

GM-A17

N/A

SONOMA (oversized radio)

2002

GM-K9210P/GM-K9210DD#

GM-1416

GM-1416-1M

GM-A16

GM-A17

N/A

SONOMA (standard radio)

2002

GM-K8204/GM-K82041E

GM-1344

GM-1343M

GM-A16

GM-A17

N/A

SONOMA

03-04

GM-K9210P/GM-K9210DD#

GM-1416

GM-1416-1M

GM-A16

GM-A17

N/A

SAVANA VAN

96-00

GM-K9505

GM-1344

GM-1343M

GM-A16

GM-A17

USPA-5060

SAVANA VAN

01-02

GM-K9210P/GM-K9210DD#

GM-1416

GM-1416-1M

GM-A16

GM-A17

USPA-5060

SAVANA VAN (w/o OnStar or amp)

03-07

GM-K9210P/GM-K9210DD#

N/A

N/A

GM-A16

GM-A17

SAVANA VAN (w/ OnStar)

03-07

GM-K9210P/GM-K9210DD#

N/A

GM-A16

GM-A17

SAVANA VAN (w/ OnStar & Bose)

03-07

GM-K9210P/GM-K9210DD#

N/A

GM-A16

GM-A17

SAVANA VAN (w/o OnStar or Amp)

08-11

GM-K0610DD#/GM-K0610DDP

N/A

N/A

CHR-A16

CHR-A17

SAVANA VAN (w/ OnStar & Bose)

08-11

GM-K0610DD#/GM-K0610DDP

N/A

CHR-A16

CHR-A17

SUBURBAN

73-77

N/A

N/A

N/A

N/R

N/R

N/A

SUBURBAN

78-87

N/A

GM-1342

GM-1341M

N/R

N/R

N/A

SUBURBAN

88-91

GM-K8204

GM-1342

GM-1341M

GM-A16

GM-A17

SUBURBAN

92-94

N/A

GM-1344

GM-1343M

GM-A16

GM-A17

SUBURBAN

95-99

GM-K9505

GM-1344

GM-1343M

GM-A16

GM-A17

GSA-FT5465

TERRAIN

2010

TERRAIN

2010

VAN (fullsize)

71-77

N/R

N/A

N/A

N/R

N/R

VAN (fullsize)

78-87

N/R

GM-1342

GM-1341M

N/R

N/R

VAN (fullsize)

88-95

GM-K8204

GM-1344

GM-1343M

GM-A16

GM-A17

YUKON

92-94

N/A

GM-1344

GM-1343M

GM-A16

GM-A17

YUKON (w/o OnStar or Amp)

95-02

GM-K9505

GM-1344*

GM-1343M

GM-A16

GM-A17

YUKON (w/ OnStar)

95-02

GM-K9505

GM-1344*

GM-1343M

GM-A16

GM-A17

YUKON (w/ OnStar & w/ Bose)

95-02

GM-K9505

GM-1344*

GM-1343M

GM-A16

GM-A17

* This harness works on standard wiring only.

Not for amplified,JBL, or premium sound systems.

** Works on standard wiring systems only.

Not for vehicles with Bose or On-Star systems.

< Requires factory mounting bracket.

# Fits Double Din or two Single ISO mount radios.

^ Requires locating a switched 12v< power source for

after-market radios.
