Vutec LECTRIC II - Installation Instructions User Manual
Page 11

10
04/21/08 Rev D
LIIe-INST_D
Figure 8
Cut out of housing and end cap removed to illustrate details
Figure 9
Housing components removed to illustrate details
WEIGHT DATA
Some standard viewing sizes are shown. Extrapolate the information for size not showing as necessary or
contact Vutec for details. Divide lbs by 2.2 to obtain kgs.
Viewing size (4:3) (HxW)
Weight (lbs)
Viewing size (16:9) (HxW)
Weight (lbs)
60 x 80
50.5 x 90
72 x 96
60 x 107
90 x 120
72 x 128
108 x 144
81 x 144
