2

Specifications:



Class microcontroller high power dimmer, suitable for incandescent lamps, mains voltage halogen lighting
and low voltage halogen lighting in combination with a conventional (wire wound) transformer.



Easy pushbutton operation for dimming of light sources.



Phase control can be disabled.



Non volatile memory for last set light intensity.



Lots of safety features to make lamps last as long as possible, such as “Softstart” and automatic turn-off
after 12h or after 20min at too low intensity.



Transformer protection in case of defective light sources.



LED status indication.

Features:

Suppression of radio & TV interference according to EN55015.

Operating voltages: 110-125V or 220-240V AC (50/60Hz)
Max. load: 1000W/230V or 500W/115V (5A)

Max. phase shift with inductive load: 30°.
Dimming speed: +/- 5 sec.

PCB dimensions: 90 x 75 x 40 mm.

Features & Specifications



It is not recommended to use this dimmer with electronic transformers !!!
