Velleman projects K3502 Assembly instructions User Manual
Page 8
8
Construction
SENS 1 : MA40A5S or eq.(marked with T).
SENS 2 : MA40A5R or eq. (marked with CTD)
Either on the print or connect them to the soldering terminals,
see chapter concerning the installation in the car.
7. Sensors
IC6 : TL074
Pay attention to the position
of the notch!
8. IC mounting
PIN 1
1
