Velleman К8091 User Manual
Page 7
7
R17 : 220 (2 - 2 - 1 - B)
Construction
SK1 : 2p
(AC IN)
SK2 : 2p
(output)
12. Terminal blocks
10. 1W Resistor
VR2 : UA78L05
9. Voltage regulator
VR...
C8 : 220µF
C9 : 10µF
11. Electrolytic capacitors.
Watch the polarity !
C...
C6 : 100nF
C7 : 470nF
13. Capacitors
SW1
SW2
SW3
14. Push buttons
TR1 : BT136
15. Triac
TR...
T1 : BC547
8. Transistor
T1
IC1: VK8091EU
Programmed PIC16F627A
16. IC
