13

CONNECTION AND USE (continued from page 11)

C- Use as a fixed display:
If no effects are wanted, and only a fixed message is needed, mount a jumpwire
at position JC, next to IC1.

1

IC1

JC


D- Speed adjustment:
The speed of the effects can be adjusted by means of RV1.
To adjust the speed in a master-slave configuration, only the master RV1 must be
adjusted (This is the unit with IC2 mounted).

RV1

SK2

GND

OSC
I/O

SPEED



shunt

Speed
adjustment

FIG 3

FIG 4
