Resistor trimmer, Ic socket. watch the position of the notch, Zenerdiode. watch the polarity – Velleman К8064 User Manual
Page 7: Resistor, Transistors, Voltage regulator, Leds. watch the polarity, Capacitor
7
Construction
RV1 : 220K
(250K)
RV2 : 2M2
(2M5)
10. Resistor trimmer
RV1
IC1 : 14p
IC2 : 6p
9. IC socket. Watch the
position of the notch!
ZD2 : 12V
8. Zenerdiode. Watch the
polarity !
ZD...
CATHODE
+/-
5mm
R20 : 220
(2 - 2 - 1 - B)
11.
1W
Resistor
R...
5mm
T1 : BC547
T2 : BC547
12. Transistors
VR1 : UA78L05
13. Voltage regulator
VR...
LD1 : 3mm Green
LD2 : 3mm Red
COLOR= 2...5
LD...
CATHODE
7. LEDs. Watch the polarity!
C12 : 100nF / 250Vac
14. Capacitor.
5mm
