Velleman К8064 User Manual
Page 3
3
Features:
Simple brightness adjustment by means of a DC voltage.
Optically isolated adjust input.
Pre-set adjustment for full brightness.
Suitable for incandescent lamps, mains voltage halogen lighting and low voltage halogen lighting in combination
with a conventional transformer.
"Soft start" feature to ensure lamp longevity.
Transformer protection in case of defective light sources.
LED status indication.
Compatible with our computer interface cards: K8000, K8055, VM110.
Specifications:
Adjustment voltage: 0 to 12Vdc max.
Max. adjustment current: 2.25mA at adjustment voltage of 12V.
Suppression of radio & TV interference according to EN55015.
Operating voltage: 110-125V or 220-240V AC (50/60Hz).
Max. load: 750W/230V or 375W/110V, 0-98% adjustable.
Max. phase shift with inductive load: 30°.
PCB dimensions: 90 x 75 x 40mm
Features & Specifications
