RST40 Product Design Changes – ABIB-0510R3
CARRIER & CAP CHANGE:
The new RST40 carrier & cap is unique in its design. The casting number located on the outside edge of the carrier
makes it visibly easy in identifying the old and new design carriers. Two new Carrier/Cap service kits have been released,
part numbers
514063 and 514064.
The 514063 kit listed below is the standard Carrier/Cap Service Kit for models built
AFTER April 1, 2005. The
514064
kit is a “Carrier/Cap Conversion Kit” that includes other parts needed to convert
original design models.
CARRIER TO HOUSING FASTENERS:
The new RST40 carrier and cap is designed with thick flange bosses, which requires different housings fasteners
compared to the old design. The individual fasters and service kits for both the OLD and NEW designs are listed below.
This bulletin contains product information.
Dana Corporation is not committed or liable for canvassing existing product.
CARRIER TO HOUSING FASTENER CHANGE:
•
•
•
•
New Design Carrier – Uses 4 long metric capscrews, 8 standard length metric capscrews & 12 washers.
•
•
•
•
Spicer P/N’s: 130837-long Capscrew, 130836-standard Capscrew and
12-130807-washers
•
•
•
•
For service use Axle Housing Hardware Kit: 514260
Original Design Carrier – Used 10 metric threaded capscrews, 2 metric threaded studs, & 2 nuts
•
Spicer P/N’s: 130836-metric capscrew, 127641-metric stud & 127567-nut
•
For service use Axle Housing Hardware Kit: 511600
CARRIER & CAP SERVICE KITS:
•
•
•
•
New Design:
Dana Kit P/N: 514063 - Casting# 130945
•
•
•
•
New Design:
Dana Kit P/N: 514064 - Casting# 130945
Original Design:
Dana Kit P/N: 211219 - Casting# 127046
KIT – CARRIER & CAP
SPICER P/N: 514063
1-130946 Carrier/Cap
KIT – CARRIER & CAP CONVERSION KIT
SPICER P/N: 514064
1-130946 Carrier/Cap
1-129768 Cage/Cup
6-210115 Capscrew
8-130836 Fasteners
4-130837 Fasteners
12-130877 Washers
