GEAR/PINION and RING GEAR NUT/BOLT CHANGE:
The actual pinion design change was described on page two of this bulletin. In addition to that change the ring gear
fasteners were also commonized to use the same fasteners as the RS404. When using the replacement gear/pinion kits
for any “Original” design axle or any axles built with the original design gearing you must use the correct nut and bolt kit
during reassembly. Refer to the charts and kit numbers below.
This bulletin contains product information.
Dana Corporation is not committed or liable for canvassing existing product.
UPGRADED GEAR/PINION KITS:
•
•
•
•
SERVICE KIT PART NUMBERS WERE NOT CHANGED
•
•
•
•
KITS NOW INCLUDE INNER PINION BEARING
•
•
•
•
IDENTIFY AXLE DESIGN BY PINION or GEAR PART NUMBERS
•
•
•
•
AXLES BEFORE APRIL 1, 2005 IN 3.55 & 3.70 RATIOS, REQUIRE CAGE/CUP UPGRADE TO
PART-NO. 128372 (REFER TO NOTE 1 AT THE BOTTOM OF PAGE 2).
513869
2.64
131874
131873
37/14
16"
513870
2.93
130947
130949
41/14
16"
511148
3.08
131842
131814
37/12
16"
511149
3.25
131843
131815
39/12
16"
511150
3.36
131844
131816
37/11
16"
511151
3.55
131845
131817
39/11
16"
511152
3.70
131846
131818
37/10
16"
511153
3.90
131848
131819
39/10
16.5"
511154
4.11
131849
131820
37/9
16.5"
511155
4.33
131850
131821
39/9
16.5"
512158
4.88
131852
131822
39/8
16.5"
512159
5.29
131853
131823
37/7
16.5"
512160
5.57
131854
131824
39/7
16.5"
512161
6.17
131857
131855
37/6
16.5"
512162
6.50
131858
131856
39/6
16.5"
SPICER
SERVICE
GEAR SET
P/N
NOTE 1: The inner pinion bearing is now included in all of these service gear sets effective
March 1st 2005.
129562
(note 1)
RING
GEAR
SIZE
INNER
PINION BRG
NOW IN KIT
NO. TEETH
RATIO
PINION P/N
GEAR P/N
•
•
•
•
Shown in the chart at the
left are the “Original” gear
part numbers and pinion
part numbers, which are No
Longer Made.
•
•
•
•
These original ring gears
use Bolt# 67586 and Nut#
60600 which are sold in
Spicer Nut/Bolt Kit: 70745
•
•
•
•
The ring gears in the kits to the left
are designed to use bolt #129686 and
nut# 126216. These are in
Spicer
Not/Bolt Kit: 508652.
•
•
•
•
On axles manufactured AFTER April
1st, 2005 use
Nut/Bolt Kit: 508652.
•
•
•
•
If you order any of these Gear/Pinion
kits and rebuilding an axle with a
“original” design ring gear, you must
also get
Spicer Nut/Bolt Kit: 508652
511148
3.08
128025
129987
37/12
16"
511149
3.25
127886
129988
39/12
16"
511150
3.36
120045
129989
37/11
16"
511151
3.55
109862
129990
39/11
16"
511152
3.70
88013
129991
37/10
16"
511153
3.90
99746
129992
39/10
16.5"
511154
4.11
86372
129993
37/9
16.5"
511155
4.33
86374
129994
39/9
16.5"
512158
4.88
86378
130873
39/8
16.5"
512159
5.29
86380
130874
37/7
16.5"
512160
5.57
86880
130875
39/7
16.5"
512161
6.17
130871
130872
37/6
16.5"
512162
6.50
86882
129160
39/6
16.5"
SERVICE
GEAR SET P/N
RING GEAR
SIZE
NO.
TEETH
RATIO
OLD
GEAR P/N
OLD
PINION
P/N
