Dimension Detail
© 2005 Dana Corporation
ø
C
ø
D
Thru Hole Diameter
1310
2-2-1329
2-2-1339
DIN Pattern Flange Yokes
øB/
PCD
Pitch Circle Diameter
ød
No. of Holes
Part Number
Series
4
6
90.0
100.0
74.5
84.0
47.0
57.0
50
50
M8
M8
1410
3-2-1239
3-2-1159
6
8
100.0
120.0
84.0
101.5
57.0
75.0
64.3
64.3
M8
M10
1480
3-2-1299
02-323
3-2-1219
8
6
8
120.0
120.0
120.0
101.5
101.5
101.5
75.0
82.5
82.5
60.0
60.0
60.0
M10
M10
M10
1550
4-2-1069
8
150.0
130.0
90.0
80.0
M12
1610
5-2-1149
8
150.0
130.0
90.0
91.9
M12
1710
6-2-1259
6-2-1309
6-2-1339
8
8
8
165.0
180.0
180.0
140.0
155.5
155.5
95.0
110.0
110.0
101.6
101.6
101.6
M16
M14
M16
1760
6.3-2-89
6.3-2-69
6.3-2-59
8
8
10
180.0
180.0
180.0
155.5
155.5
155.5
110.0
110.0
110.0
108.0
108.0
108.0
M14
M16
M16
1760
6.3-2-89
6.3-2-69
6.3-2-59
8
8
10
180.0
180.0
180.0
155.5
155.5
155.5
110.0
110.0
110.0
108.0
108.0
108.0
M14
M16
M16
All Measurements in Millimeters
M - Flange Face
to Centerline FF-
CL
øD
øB/
PCD
ø
C
ø
d
M
