Spicer Universal Joint Kits - Manual

1 Dimension Detail
© 2005 Dana Corporation
Figure Series Part Number Inches Millimeters Inches Millimeters Inches Millimeters Inches Millimeters Inches Millimeters
ø B (Bearing Diameter) D (Overall Span) BC (Bolt Hole Centers) Cross Length
1
1
1
1
2
2
2
2
2
1310
1410
1480
1550
1610
1710
1760
1810
1880
5-153X
5-160X
5-263X
5-275X
5-279X
5-280X
5-407X
5-281X
5-380X
1.06
1.18
1.37
1.37
1.88
1.94
1.94
1.94
2.18
26.9
29.9
34.8
34.8
47.7
49.3
49.3
49.3
55.4
3.22
4.18
4.18
4.96
5.31
6.09
6.99
7.55
8.09
81.8
106.2
106.2
126.0
134.9
154.7
177.5
191.8
205.5
-
-
-
-
2.31
2.43
2.43
2.43
2.81
-
-
-
-
58.7
61.7
61.7
61.7
71.4
2.96
3.93
3.87
4.65
4.99
5.77
6.68
7.25
7.59
75.2
99.8
98.3
118.1
126.7
146.6
169.7
184.2
192.8
0.65
0.76
0.88
0.88
1.26
1.26
1.26
1.26
1.37
16.5
19.3
22.4
22.4
32.0
32.0
32.0
32.0
34.8
Universal Joint Kits
Figure Series Part Number Inches Millimeters Inches Millimeters Inches Millimeters Inches Millimeters Inches Millimeters
ø B (Bearing Diameter) D (Overall Span) BC (Bolt Hole Centers) Cross Length
Journal Cross Trunnion
Diameter
3
3
3
3
1610
1710
1760
1810
5-674X
5-442X
5-677X
5-6-768X
1.88
1.94
1.94
1.94
47.8
49.3
49.3
49.3
5.31
6.09
6.99
7.55
134.9
154.7
177.5
191.8
2.31
2.43
2.43
2.43
58.7
61.7
61.7
61.7
4.99
5.77
6.68
7.25
126.7
146.6
169.7
184.2
1.26
1.26
1.26
1.26
32.0
32.0
32.0
32.0
Universal Joint Kits for Half Round End Yokes
Journal Cross Trunnion
Diameter
