Axle Shafts
Axle Shafts
Dana S110 series axle shafts are used in “sets,” have unequal shaft lengths and may be “location specific” or “Wheel Equipment specific.” When
replacing S110 axle shafts, locate the axle shaft part number or select the correct axle shaft from the chart below before placing your order. DO NOT
MISPLACE AXLE SHAFTS FROM THEIR INTENDED LOCATION.
Part No.
Qty
Spline
Body O.D.
Shaft Length
Spline Length
Flange O.D.
Flange Holes
OEM
130523
1
34
1.56
39.290
3.23
6.079
8 (485-STR)
Ford
130524
1
34
1.56
41.000
3.23
6.079
8 (485-STR)
Ford
130610
1
34
1.56
37.480
3.23
6.223
8 (590-STR)
Workhorse
130611
1
34
1.56
39.173
3.23
6.223
8 (590-STR)
Workhorse
132856
1
34
1.56
38.740
2.56
6.223
8 (781-TPR)
GM
132857
1
34
1.56
40.433
2.56
6.223
8 (781-TPR)
GM
132858
1
34
1.56
40.287
2.56
6.079
8 (485-STR)
Ford
132859
1
34
1.56
42.000
2.56
6.079
8 (485-STR)
Ford
133684
1
34
1.56
38.091
2.56
6.223
8 (590-STR)
Android
133685
1
34
1.56
40.433
2.56
6.223
8 (590-STR)
Android
Wheel Attaching Hardware
Part No.
Description
Qty
Notes
45816
Axle Shaft Bolt
16
47857
Axle Shaft O-Ring
2
47860
Oil Seal - Wheel
2
replaces 131800
550348
Bearing Cone - Outer Spindle
2
566071
Bearing Cone - Inner Spindle
2
2001857
Locknut - Brake to Housing
10
Note: Contact your OEM for wheel attaching parts not listed.
Wheel Seal Repair Kit
Part No.
Description
Qty
Notes
513981
KIT-WHEEL SEAL REPAIR (w/tool)
Kit includes pts below and the Seal Driver Tool
513982
KIT-WHEEL SEAL REPAIR (less tool) Kit includes pts below less the Seal Driver Tool
47860
Oil Seal - Wheel
2
131664
Speedi Sleeve
2
133632
Tool - Seal Installation
1
133633
Sealant - Loctite 609
1
10ml tube
