Page 10

Carrier & Cap Kits / Pinion Brg Spacers

Carrier Sub-Assembly - Item #10

Carrier & Cap Kit

Sub Assy

Base Part

Casting

Notes

Part Number

Number

514121

130511-NSS

130747-NSS

130500

ABS Design - Ford

504044

130739-NSS

130748-NSS

130737

Parking Brake Opt. - Workhorse

511860

130994-NSS

130746-NSS

130500

Standard Non-ABS - Ford/Gm/Workhorse

Diff Carrier & Bearing Caps Kit - 514121 abs design (Includes Items 5, 7, 10-15 page 7)

Diff Carrier & Bearing Caps Kit - 504044 parking brake desgin (Includes Items 5, 7, 10-13 page 7)

Diff Carrier & Bearing Caps Kit - 511860 non-abs design (Includes Items 5, 7, 10-13 page 7)

Pinion Bearing Spacers

Pinion Bearing Spacer Kit P/N: 504039

Part Number

Spacer (mm)

Thickness (in)

130543

27.230

1.072

130545

27.280

1.074

130547

27.330

1.076

130549

27.390

1.078

130551

27.440

1.080

130553 *

27.490

1.082

130555

27.540

1.084

130557

27.590

1.086

130559

27.610

1.087

130561

27.640

1.088

130563 *

27.660

1.089

130565 *

27.690

1.090

130567 *

27.720

1.091

130569

27.740

1.092

130571

27.770

1.093

130573 *

27.790

1.094

130575 *

27.820

1.095

130577 *

27.840

1.096

130579

27.870

1.097

130581

27.890

1.098

130583 *

27.920

1.099

130585

27.940

1.100

130587

27.970

1.101

130589

28.000

1.102

130591

28.050

1.104

130593

28.100

1.106

*Most popular used spacers. Brg Spacer Kit 504039 contains qty 1 each of these items.
