Spicer New Cast Iron Cover Inter-axle Differential Lockout units - Manual (Page 3)

Original Design Lockout - (Standard Air & Navistar Rev-Air Type)
Models
: All standard air "D" series axles built before 1988 (except 44D models)
All Navistar Reversed-air axles (except current D404 models)
Item No. Description Qty. A B C D E F G
1 Shift Cylinder Body 1 32828 32828 32828 96913 96913 32828 32828
2 Piston 1 32834 32824 32834 96915 96915 32834 32834
3 Piston Stop 1 102616 ------ ------ ------ ------ 102616 ------
4 O-Ring 1 32832 32832 32832 32832 32832 32832 32832
5 Piston Felt Oiler 2 96916 96916 96916 96916 96916 96916 96916
6 O-Ring 1 32826 32826 32826 ------ ------ 32826 32826
7 Push-Rod Flat Washer 1 111406 111406 111406 111406 111406 111406 111406
8 O-Ring 1 60817 60817 60817 60817 60817 60817 60817
9 Cyliner Cover 1 32831 32831 32831 32831 96914 32831 32831
10 Capscrew 4 79363 79363 79363 79363 79363 79363 79363
11 Lockwasher 4 90419 90419 90419 90419 90419 90419 90419
12 Locknut 1 1006779 1006779 1006779 1006779 1006779 1006779 1006779
13 Body Capscrew 2 90031 90031 90031 90031 90031 21385 111313
14 Lockwasher 2 90415 90415 90415 90415 90415 90415 90415
15 Shift Fork Assy. 1 102613 45859 103529 107620 76715 111372 111372
16 Compression Spring 1 31038 31038 31038 126705 126705 31038 31038
17 Cover Reducer Bushing 1 ------ ------ ------ 108223 ------ ------ ------
18 O-Ring 1 ------ ------ ------ 96912 96912 ------ ------
19 O-Ring 1 ------ ------ ------ 96911 96911 ------ ------
Gasket Compound AR 107276 107276 107276 107276 107276 107276 107276
K
Air Lockout Kit w/Fork NLA NLA 104819 107621 96919 NLA 113584
I
Retofit Kit w/Fork 508506 508457 508457 N/A N/A N/A N/A
T
Complete Retrofit Kit w/fork* 217792 217793 217794 N/A N/A 217795 217796
S
Lockout Body Kit 104599 34779 34779 N/A N/A 104599 34779
Repair Kit 211201 211201 211201 211202 211202 211201 211201
* Retrofit kits are the Cast Iron design.
A D402-P Series w/Lube Pump
B D402 Series w/o Lube Pump
C D461-P
D D402-P Series (Navisatar reversed-air) w/ Lube Pump
E D402 Series (Navistar reversed-air) w/o Lube Pump
F D402-P Axles for Front Axle Lockup used in 4 x 4 & 6 x 6 Applications
G D461-P Axles for Front Axle Lockup used in 4 x 4 & 6 x 6 Applications.
