General Information
G
ener
al I
n
for
m
ation
Model Number Location
If Drive Axle is LMS™, as shown on the hub, see page 30 for removal and assembly procedures.
If Drive Axle is Standard, see page 28 for removal and page 48 for assembly procedures.
Axle Data Plate
Note: Tags that do not include all the information shown here are older models (before May 1987).
1 - Country or origin
2 - Axle model identification
3 - Specification number assigned to the axle built by Spicer. Identifies all component parts of the axle including special OEM
requirements such as yokes or flanges
4 - OEM part number assigned to the axle build
5 - Carrier assembly serial number assigned by the manufacturing plant
6 - Axle gear ratio
7 - Carrier assembly production or service part number
Data plate is located on
the axle centerline
Forward Axle (Side View) Rear Axle (Top View)
4
6
5
1
3
2
7
Spicer ®
MODEL PART NO. RATIO
MADE IN:
SPEC. SERIAL NO.
CUST. PART NO.
Spicer®
MODEL PART NO. RATIO MADE IN:
SPEC. SERIAL NO. CUST. PART NO. Spicer®
MODEL PART NO. RATIO MADE IN:
SPEC. SERIAL NO. CUST. PART NO.
ID Tag
PT . N O.
HS G. CA P.
L BS .
HS G. I.D . N O.
HO US ING M AD E I N
Sp icer
®
Part Number
Axle Housing ID Tag Axle Shaft Part Number
