Spicer Dana LMS Hub Assembly Procedure – Steer and Drive Axles - Manual

WARNING: Do not attempt to make LMS™ hubs by using LMS™ bearing, spacer and seals in a standard hub.
This may result in a seal or bearing failure, which may result in loss of wheel end and or loss of vehicle control.
08/05 1 of 11 shais171
Spicer

Drive Axles
SHAIS171
Information
Sheet
Topic: Dana LMS ™ Hub Assembly Procedure – Steer and Drive Axles
Note: Bulletin ABIB-0302 replaces the original bulletin ABIB-9606.
The Dana LMS™ hub design eliminates bearing adjustment and variables that cause excessive endplay leading to
premature wheel seal failures.
The Dana LMS™ hub design combines proven seal technology with precision-manufactured bearing spacers and special
tolerance bearings.
The Dana LMS™ Hub is available on the following Steer and Drive Axle Models:
Steer Axles:
E-1000I E-1202I E-1462I
E-1200I E-1460I E-1320I
Drive Axles:
All “R” series spindles only.
WARRANTY COVERAGE
Installation of the LMS™ Hub requires certification by Dana. The Dana LMS™ Hub is covered for 3 years/350,000 miles for
On/ Off-Highway applications, when installation is performed by certified installers, and Dana approved synthetic lubes are
used.
CAUTION: The wheel seal cannot be reused. Any time the hub is removed from the spindle, the seal must be
replaced. Failure to follow this requirement will void warranty.
